5.3.21 Initial Setting Screen 6

No. Item
1 TEMP BAND
2 READY TIME
HRZF Series
1
2
Fig.5-24 Initial Setting Screen 6
Table 5-21 「Initial Setting Screen 6」
Descriptions
Allows the setting of band range to TEMP
PV.
Allows the setting of time from when
TEMP PV reaches the BAND range to
when "TEMP READY" is displayed on
operation display panel and Ready signal
is output.
【Tips】
See "8.5 BAND/READY" on page 8-16.
[▲] or [▼] key is used for selecting "Item" and move to other Initial
Setting screens. And pressing the [ENT] key enabling to select the
setting.
Chapter 5 System Operation
POWER ON
Setting Range
1.0 to 99.9 deg C
1 to 999s
DOC1046494-2
Factory
Default
1.0 deg. C
60s
5.3 Operation Screen
5-23
