Bar Codes
Mode - 0
This parameter is used to set the mode to be used in generating the Aztec barcode. A
value of 0 generates a standard Aztec while a setting of 2 would use the GS1 specification.
Please note that if the GS1 is used, the application identifiers should be entered with
brackets, Example: [21]123
8.1.25 QR Code, TCI 53
QR Code is a high density 2 dimensional barcode that can encode up to 3990 characters.
QR Code was designed for high-speed component scanning
The D194 command is used to receive and process the QR Code barcode with the
elements discussed below.
Once the QR Code barcode data is entered and processed, the barcode image may be
placed using the normal format field by using a TCI of 53.
The sample below shows how to generate a data matrix symbol:
^D194 <---------------------------------Start of QR Code Data
0 <----------------------------------------Size
0 <----------------------------------------Minimum error correction
0 <----------------------------------------Mode
:0123456789^\<---------------------- Data to encode
^D57
2,832,300,,38,6,2,1,285,0,0
1,336,75,1,53,,0,4,10,10 <---------- Multiplier (10, 10); TCI 53
1,336,25,11,7,10,0,4,2,2,,,,,0
^D56
^D2
QR CODE
^D3
8-26
Minimum Err Correction
0 Auto
1 10% + 3 words
2 23% + 3 words
3 36% + 3 words
4 50% + 3 words
Table 8-10 Aztec Minimum Error Correction
Modes
0 Standard
1 Reserved
2 GS1*
Table 8-11 Aztec Modes
