7. Enter the IP address of your TFTP server into the TFTP Server IP parameter field.
8. Enter the firmware filename of the file to be uploaded into the New Filename parameter field.
9. Click Upload File.
Note
10. Repeat steps
Web Page Item
System Configuration
Bootname
Kernel
VoIP Loudspeaker Amplifier Operations Guide
For example, kernel filename "201-image-spk-sip.bin".
This starts the upload process. Once the speaker has uploaded the file, the Uploading
Firmware countdown page appears, indicating that the firmware is being written to flash.
The speaker will automatically reboot when the upload is complete. When the countdown
finishes, the Firmware Upgrade page will refresh. The uploaded firmware filename should
be displayed in the system configuration (indicating successful upload and reboot).
8
and
9
if you are uploading the Kernel and Application files.
For example, Application filename "201-romdisk-spk-sip.img".
Table 2-13
shows the web page items on the Firmware Upgrade page.
Table 2-13. Firmware Upgrade Parameters
Upgrade the Firmware and Reboot the Loudspeaker Amplifier
Figure 2-14. Firmware Upgrade Page
Description
Shows the current configuration.
Shows the current boot loader filename.
Shows the current kernel filename for partition 1 and 2.
930106D
Installing the VoIP Loudspeaker Amplifier
CyberData Corporation
25
