5. Structural Drawing, Option and Replacement Parts

Option
No. Part name
(1)
Bracket assembly
Note 1) Assembly of 2 types of bracket and 2 set screws.
Replacement Parts
No. Part name
(2) Bowl seal
Bowl assembly
(3)
Auto drain (N.C.)
Auto drain (N.O.)
Note 1) The numbers in the table and structural drawing are consistent with the numbers in [10. How to Replace the
Components] (P22-25) and [11. Disassembly Drawing] (P26).
Structural drawing / Option / Replacement parts
AFG20-D
AFG20-D
Note 1)
AF24P-070AS
AFG20-D
C2SFP-260S
Refer to the section [6. Bowl Assembly Specifications] (P10-P17).
AFG30-D/ AFG40-D
(1)
(2)
(3)
Part No.
AFG30-D
AF34P-070AS
Part No.
AFG30-D
C32FP-260S
9
AFG40-D AFG40-06-D
AF44P-070AS AF49P-070AS
AFG40-D AFG40-06-D
C42FP-260S
