Contents PAGE 1. PRECAUTION FOR SAFETY 1~8 2. APPLICATION SPECIFICATIONS. . 4. SERIESMAP AND COMBINATION OF EQUIPMENT. . 5. HOW TO ORDER 11~15 6. ATTACHMENTS / ACCESSORIES(OPTIONS)PART NUMBER 7. TROUBLE SHOOTING 8. SPARE PARTS LIST 9. HOW TO REPLACE 10. DISASSEMBLY DRAWING 18~19 11.
Page 3
AIR COMBINATION Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC), 1) 2) Japan Industrial Standards (JIS)
Page 4
AIR COMBINATION Safety Instructions Caution The product is provided for use in manufacturing industries. The product herein described is basically provided for peaceful use in manufacturing industries. If considering using the product in other industries, consult SMC beforehand and exchange specifications or a contract if necessary.
Page 5
Precautions for design ! WARNING ○ Air combination ① Consult SMC if no leakage is allowed due to the environment, or operating fluid is not air. ② External parts including the bonnet (material: polyacetal), bowl, sight dome (material: polycarbonate) are made of resin. Organic solvents including synthetic fluid, chemicals including acetone, alcohol, ethylene chloride, sulphuric acid, nitrate, hydrochrolic acid, cutting oil, kerosene, gasoline, lock material of screw are harmful.
Page 6
○ Air filter, Lubricator, Filter-regulator and Mist separator ① Avoid the application where charge and discharge of pressure to bowl is switched frequently. This may damage the bowl. A metal bowl is recommended in these cases. ○ Regulator and Filter-regulator ①...
Page 7
Installation ! WARNING ○ Air combination ① Connect the product ensuring the direction of " 1 " (IN) and " 2 " (OUT) for air direction or an arrow. Wrong connection may cause malfunction. ② Install with enough space around each assembly component to perform regular maintenance and operation.
Page 8
⑥ Outlet pressure may change if filter regulator is used for long periods. Please confirm set pressure regularly. ⑦ When pressure difference between the inlet side and the outlet side is large, chattering may occur. In that case, please reduce and use pressure difference between the inlet side and the outlet side.
Page 9
Maintenance ! WARNING ○ Air combination ① Maintenance and checks should be done by following the procedure in the operation manual. Incorrect handling of the product may cause breakage or malfunction of the equipment or device. ○ Air filter, Lubricator, Filter-regulator and Mist separator ①...
Page 10
! CAUTION ○ Regulator and Filter-regulator ① If the first operation is performed and defective setting and the exhaust leakage is found, it is likely there is foreign object in an internal valve seat part. Failure to remove these parts may cause damage to internal parts.
Note2) When compressor oil mist discharge concentration is 30mg/m (ANR). Note3) Bowl seal and other O-rings are slightly lubricated. Mass (kg) * : Symbol Model (AC10-A to AC40-06-A) (AC10A-A to AC40A-06-A) (AC10B-A to AC40B-06-A) (AC20C-A to AC40C-06-A) (AC20D-A to AC40D-06-A) - - AC10*-A 0.27...
The auto drain port comes with φ3/8" One-touch fitting (applicable to the AC25-A to AC40-A). for 0.2 MPa type (1.0 MPa pressure gauge only for the AC10-A). Note 14) Without a valve function Note 7) Not available with piping port size: 06 Note 15) The combination of metal bowl: 2 and 8 is not available.
Page 14
03 DG AC 30 ・Option / Semi-standard : Select one each for a to l. ・Option / Attachment / Semi-standard symbol : When more than one specification is required, indicate in alphanumeric order. Example) AC30A-03DM-KSV-13NR-A Symbol Description Body size ● -...
Page 15
・Option / Semi-standard : Select one each for a to j. 03 DG AC 30 ・Option / Attachment / Semi-standard symbol : When more than one specification is required, indicate in alphanumeric order. Example) AC30B-03DM-SV-1NR-A Symbol Description Body size ● -...
Page 16
・Option / Semi-standard : Select one each for a to j. 03 DG AC 30 ・Option / Attachment / Semi-standard symbol : When more than one specification is required, indicate in alphanumeric order. Example) AC30C-03DM-SV-1NR-A Symbol Description Body size Rc ●...
Page 17
・Option / Semi-standard : Select one each for a to j. 03 DG AC 30 ・Option / Attachment / Semi-standard symbol : When more than one specification is required, indicate in alphanumeric order. Example) AC30D-03DM-SV-1NR-A Symbol Description Body size Rc ●...
6. ATTACHMENTS / ACCESSORIES (OPTIONS) PART NUMBER Attachments / Accessories (Options) part number Model Descriptio For AC10*-A For AC20*-A For AC25*-A For AC30*-A For AC40*-A For AC40*-06-A Standard G27-10-01 G36-10-□01 G46-10-□01 Note1) Round type Pressure Note2) G36-4-□01 G46-4-□01 0.2 MPa setting G27-10-01 gauge -...
9.HOW TO REPLACE ! WARNING ・Before replacement, ensure that the air combination assembly is not pressurized. ・Rotate the pressure adjusting handle of the regulator and filter-regulator to zero. ・Replace refering to "10. DISASSEMBLY DRAWING" (P18 to P19). ・After replacement, ensure that specified function is satisfied and external leakage is not found before starting operation. ○ Air combination Process Procedure...
Page 27
Revision history A P16 9.HOW TO REPLACE 【Precautions for modular connection (Assembly)】is added. Jan 2013 B Addition : Nylon bowl, Metal bowl, AC10-A The shape of spacer changed. June 2015 C P5 Installation CAUTION Air combination ③ is added. July 2018...
