oVerVIew
Main Features (Cont .)
DVI-I and HDMI Video Support
The Switches support varied video inputs of DVI-I and HDMI. DVI model supports
HDMI and VGA via compatible cables.
VDT Switching
VDT enables easy switching of keyboard and mouse by moving mouse based on
4 possible presets for monitor positioning.

Resolutions Supported

Switches support video resolutions of up to 4K-2K Ultra HD (3840 X 2160 pixels).

Audio Switching

Allows you to share speakers and headphones between computers.
Toggle Audio feature
Front panel Toggle Audio button enables to leave audio in a specific channel.
Vertiv 4-Port Secure KVM Mini-Matrix
1 2
Filtered USB (DPP) feature (applicable models)
DPP feature enables to connect authorized USB devices to product. Product is
designed with complete isolation between DPP data, such as user authentication
smart card reader data, and all other product traffic.
The DPP feature can be managed via Configurable Device Filtering (CDF)
mechanism with configuration permissions limited to authenticated
administrators. For more details please refer to the "DPP Configuration Manual".
"Freeze DPP" feature
Dedicated "Freeze DPP" slider on front panel enables to lock this function to
a specific channel. When locked, switching channels will not affect processes
performed by the USB device connected to the locked channel.
3 4 5 6
