Product Specifications - Vertiv Cybex SCM145 User Manual

SEC TIONS
Table of Contents
oVerVIew

Product Specifications

Enclosure
Power Requirements
AC Input
No . of Secure Channels
No . of Users Supported
Displays Supported
Resolution Support
Console Keyboard Input
Console Mouse Input
Console DPP Input
Console Display Port
Console Audio Out
CPU Keyboard/Mouse Ports
Vertiv 4-Port Secure KVM Mini-Matrix
1
Metal enclosure
35W internal
100 to 240VAC
4
2
Cybex SCM145: DVI-I DIsplays (Supports HDMI
and VGA via compatible cables)
Cybex SCM145H: HDMI DIsplays
Cybex SCM145 supports up to HD resolutions
(1920 X 1200 pixels).
Cybex SCM145H supports up to 4K-2K Ultra HD
resolutions (3840 X 2160 pixels).
USB Type-A female connector or PS/2 Mini-DIN
6 pin female connector
USB Type-A female connector or PS/2 Mini-DIN
6 pin female connector
USB Type A
Cybex SCM145: 2 x DVI-I female connectors
Cybex SCM145H: 2 x HDMI female connectors
1/8" (3.5mm) stereo jack
USB Type-B jack
2 3
CPU DPP Ports
CPU Audio Input
Front Panel indicators
CPU Video Input Port
Operating Temp
Storage Temp
Humidity
Warranty
Product design life-cycle
4 5
USB Type-B jack
1/8" (3.5mm) stereo jack
CAPS LOCK, NUM LOCK, SCL LOCK
Freeze audio and Freeze DPP controls
Cybex SCM145: DVI-I female connector
Cybex SCM145H: HDMI female connector
32° to 104° F (0° to 40° C)
-4° to 140° F (-20° to 60° C)
0-80% RH, non-condensing
2 years
10 years
