oPeraTIon
3 . Product Mapping to Sources
Product mapping to sources is indicated by stickers/labels specifying which
channel is mapped to which computer.
4 . Front Panel Push-Buttons
Following power up, the default channel is #1.
The user can select any other channel by pressing the appropriate front panel
push button.
The mouse cursor will be positioned at the center of the selected computer
display. If computer is connected to multiple displays, the cursor will be
positioned at the center of the primary display.
The currently selected channel is indicated by white color illumination of the
appropriate push-button.
Once a different channel is selected – video, keyboard, mouse, audio and
DPP functions follow selected channel, unless Freeze DPP function has been
activated (see below for details).
5 . DPP Port (applicable models)
The product is equipped with DPP port enabling connectivity to external USB-
devices such as smartcard reader.
The filtered USB function (DPP) enables to control which USB devices will be
operative when connected to product.
For more details on configuration options, please refer to the "DPP Configuration
Manual".
Vertiv 4-Port Secure KVM Mini-Matrix
1 2
Summary of rules that apply to DPP switching:
It is assumed that a "connected channel" is when:
1. Product is powered ON
2. The USB device connected to product console is qualified and ready for use,
as indicated by the DPP status LED illuminating steady green.
3. The channel DPP port on product is connected via USB cable to a USB port
on computer.
• When the USB device connected to the DPP console port is qualified, the
DPP status LED on the front panel would illuminate steady green.
– When connecting a USB device that is not qualified or rejected for
– When connecting a USB device to the product's DPP port that is
• Since channel #1 is the default active channel after power up and in case
only some of the channels operate with a USB device, it is recommended
to make sure computer #1 is connected to USB device.
• Once the user switches channels, for example to channel #3, DPP
functionality will move to computer #3 and be indicated by channel #3
DPP LED turning steady green.
• In case user switches to a channel that is not connected to a USB device,
the previous USB connection will be terminated and no new connection
will be established.
3 4
security reasons to the product's DPP port, the DPP LED will flash green
and USB device will be inoperable. In such case the USB device must be
replaced with a qualified device.
undetectable for any reason (e.g. failed device, non-standard device etc.),
the DPP LED will not illuminate at all and USB device will be inoperable.
In such case the USB device must be replaced with a qualified device.
5 6
