InSTallaTIon
Installation
Step 1 – Connecting devices to product console
Product requires connection of all devices and computers prior to powering it up.
Note: some devices such as user display would not be recognized if
connected after product is already powered up.
See figures above for connector locations.
• Connect user display. Mark which display is coupled with which computer.
It is also recommended to mark which computer is coupled with which
channel.
• Connect user keyboard and mouse to console keyboard and mouse ports.
• Connect headphones/speakers to console audio out port (optional).
• If the computer uses a smart card reader/USB device, connect the smart
card reader/USB device to the console DPP port (optional, model pending).
Vertiv 4-Port Secure KVM Mini-Matrix
1 2
Notes:
1. Console USB keyboard and mouse ports are switchable, i.e. you can
connect keyboard to mouse port and vice versa. However, for optimal
operation it is recommended to connect USB keyboard to console USB
keyboard port and USB mouse to console USB mouse port.
2. For security reasons products do not support wireless keyboards. In any
case do not connect wireless keyboard to product.
3. Non-standard keyboards, such as keyboards with integrated USB hubs and
other USB-integrated devices, may not be fully supported due to security
policy. If they are supported, only classical keyboard (HID) operation will be
functional. It is recommended to use standard USB keyboards.
4. Console USB mouse port supports Standard KVM Extender composite
device having a keyboard/mouse functions.
3 4 5 6
