oVerVIew
Features – Cybex SCM145 Rear Panel
1 2 3
NOTICE!
This RCU
port has not
been certified
by Common
Criteria.
8830-16646 Rev. A00
12 13
1
DPP console jack
2
DPP LED
3
Remote control (non-operative, for future use)
4
Audio Output Jack
5
USB Console Keyboard and Mouse Jack
6
PS/2 Keyboard Jack
Vertiv 4-Port Secure KVM Mini-Matrix
1
4 5 6 7 8 9 10
14 15 16
7
PS/2 Mouse Jack
8
Keyboard and Mouse Input Jack - Computer #4
9
Audio Input Jack - Computer #4
10
USB Jack - Computer #4
11
Power Input Jack
12
Restore to default
2 3
13
14
15
16
4 5
11
User Display #2 output DVI-I video jack
User Display #1 status LED
User Display #1 output DVI-I video jack
No. 4 computer display DVI-I video input jack
