InSTallaTIon
Step 4 – DPP Installation (applicable models)
In case computer and product support DPP functionality, such as user
authentication smart card reader, do the following:
1. Connect USB device, such as smart card reader, to DPP port on product
console
2. Connect DPP input port on product to any free USB port on computer using
a USB cable.Note: Do not connect the USB cable if DPP functionality is not
needed for that computer.
If only some of the computers use DPP functionality, such as user authentication,
make sure that computer #1 is connected to the USB device. If needed, switch
channels/computer mapping to create this configuration.
When product is powered ON and connected USB device is qualified and ready
for use, the DPP status LED will illuminate steady green.
In case the connected USB device cannot be detected by the secure product, the
DPP status LED will not illuminate at all.
The USB device will be detected only if it is fully compliant with USB 1.1 or USB
2.0 standard and is included in the list of recognized USB devices defined by the
administrator when configuring DPP functionality.
Vertiv 4-Port Secure KVM Mini-Matrix
1 2
Possible reasons for USB device not being detected:
• Non-standard USB device
• Device only operating in USB 3.0 mode
• Failed USB Device
In this case you will have to use a different USB device.
If the device is detected but is not authorized, the device will be rejected for
security reasons. This will be indicated by DPP status LED flashing green.
Smart card readers and CACs are included in the authorized USB devices list by
default.
