oVerVIew
USB Mouse console port
The product console USB mouse port is compatible with standard USB mice.
Notes:
a. Console USB keyboard and mouse ports are switchable, i.e. you can
connect keyboard to mouse port and vice versa. However, for optimal
operation it is recommended to connect USB keyboard to console USB
keyboard port and USB mouse to console USB mouse port.
b. Console USB mouse port supports Standard KVM Extender composite
device having a keyboard/mouse functions.
c. For security reasons products do not support wireless mice. In any case
do not connect wireless mouse to product.
PS/2 Mouse and Keyboard console ports
The product console PS/2 keyboard and mouse ports are compatible with
standard PS/2 keyboards and mice.
Vertiv 4-Port Secure KVM Mini-Matrix
1 2
User Display
The Switch console video port is compatible with the following types of displays:
• Cybex SCM145 supports DVI-I displays as well as VGA and HDMI via
compatible cables.
• Cybex SCM145H supports HDMI displays.
User Audio Devices
Product is compatible with the following types of user audio devices:
• Stereo headphones;
• Amplified stereo speakers.
Note: In any case do not connect a microphone to product audio output port
including headsets.
3 4 5 6
11
