TroubleSHooTInG
Video
No video image in user display (all channels)
• Check that displays are properly powered.
• Check that video cable is properly secured at both sides.
• Check at the displays' on-screen menu that sources selected match the
cables connected to displays.
• Check if display video mode is the same as computer's video mode (e.g.
DVI and DVI, etc.).
• Check that displays' diagnostic LED is steady green – if not, change
displays, change displays' cables or call technical support.
No video image in user display (specific channel)
• Reboot product first, then disconnect and reconnect the video cable and
reboot the computer.
• Check that the video cable connecting computer and product is properly
secured at both sides.
• Check that computer video output is sent to the connected video
connector (if computer supports multiple displays).
• Check that computer resolution matches connected display capabilities.
• Connect the display/s directly to the computer to confirm that video
output is available and that a good image is shown.
Vertiv 4-Port Secure KVM Mini-Matrix
1 2
Bad video image quality (some or all channels)
• Check that all video cables are properly connected to product, computer,
and display.
• Check that cables are original cables supplied by Vertiv.
• With everything connected, power-cycle the product to reset the video.
Make sure the Video Diagnostic LED is solid green.
• Check that the displays that you are using support the resolution and
refresh-rate setting on computer.
• Lower the video resolution of your computer.
• Connect displays directly to computer showing bad video image to see if
problem persists.
