Step 2 – Connecting the Computers
• Using USB cables, connect each computer to the USB type B port in
"computer interface ports" area on product.
• If computer uses audio output, e.g. speakers/headphones, connect audio
cable from its audio output port to the corresponding audio input port
on product.
• If the computer uses a smart card reader/USB device, connect a USB cable
between the DPP-enabled computer and the corresponding DPP port on
product.
Note:
1. If the number of product channels is larger than the number of sources
used, make sure the computers are connected in a row starting from
computer #1. For example, if there are 3 channels used, connect computers
to channels #1, #2 and then #3.
2. The USB cable must be connected directly to a free USB port on the
computer, with no USB hubs or other devices in between.
Vertiv 4-Port Secure KVM Mini-Matrix
1 2
Step 3 – Power up
• Connect AC power cord.
• Power up user display/s. Select through display setup menu the
appropriate video input if applicable.
• Power up the connected computers.
• Power up the product.
When you power up your computers, the product emulates display, mouse
and keyboard on each port and allows your computers to boot normally. You
should be able to move the mouse cursor on the primary display connected to
computer #1.
Check to see that the keyboard and mouse are working properly on each
computer.
Repeat this check with all occupied ports to verify that all computers are
connected and responding correctly.
If you encounter an error, check your cable connections for that computer and
reboot. If the problem persists, please refer to the Troubleshooting section in
this User Manual.
