MAX22216-EVAL Evaluation Board • 319-101029, Rev 1: 03/24
8/17
3.3.1 Landungsbruecke Connector
All signals are connected to the MAX22216 directly without any additional protec-
NOTE
tion. Refer to the MAX22216 data sheet for electrical ratings.
Figure 7: Pin Assignment on Landungsbruecke Connector
