Backyard Discovery TIMBER CROSSING Manual page 8

Owner's Manual - Parts Identification
M04
FLOOR BOARD - W4L18584
(x2) 5/8"x3 3/8"x21 1/4" (16x86x540)
M06
FLOOR BOARD - W4L18587
5/8"x3 3/8"x29" (16x86x736)
(x1)
M11
TOP BOARD - W4L18605
5/8"x3 1/4"x31" (16x82x786)
(x2)
M13
ROCK WALL BOARD - W4L18607
5/8"x3 3/8"x28 1/8" (16x86x714)
(x4)
M15
GABLE BOARD - W4L18622
5/8"x3 3/8"x18 1/4" (16x86x465)
(x4)
N02
ROOF CLEAT - W4L18623
(x4) 5/8"x2 3/8"x26 5/8" (16x60x675)
Wood Components (Not to Scale)
M02
FLOOR BOARD - W4L18579
(x11) 5/8"x3 3/8"x21 1/4" (16x86x540)
M03
FLOOR BOARD - W4L18580
5/8"x3 3/8"x54 5/8" (16x86x1389)
(x13)
M08
WALL BOARD - W4L18591
5/8"x3 1/4"x26 7/8" (16x82x684)
(x7)
M10
WALL BOARD - W4L18600
5/8"x3 3/8"x53 1/4" (16x86x1354)
(x4)
M73
REAR SUPPORT - W4L18558
(x1) 5/8"x3 3/8"x20 1/8" (16x86x512)
N01
CLEAT - W4L18611
5/8"x2 3/8"x51 1/8" (16x60x1297)
(x2)
SP71
SWING BEAM SUPPORT - W4L18632
3 3/8"x3 3/8"x43 3/8" (86x86x1102)
(x1)
M05
FLOOR BOARD - W4L18586
(x15) 5/8"x3 3/8"x29" (16x86x736)
M07
WALL BOARD - W4L18589
5/8"x3 3/8"x29" (16x86x736)
(x12)
M12
ROCK WALL BOARD - W4L18608
5/8"x3 3/8"x28 1/8" (16x86x714)
(x3)
M14
ROCK WALL BOARD - W4L18606
5/8"x3 3/8"x28 1/8" (16x86x714)
(x17)
M16
GABLE BOARD - W4L18624
5/8"x3 3/8"x11 3/4" (16x86x300)
(x4)
N06
FILLER BOARD - W4L18609
5/8"x1 3/4"x28 1/8" (16x44x714)
(x1)
