Backyard Discovery TIMBER CROSSING Manual page 7

Owner's Manual - Parts Identification
H25
WALL RAIL - W4L18628
1"x3 3/8"x29" (24x86x737)
(x1)
H27
WALL RAIL - W4L18593
1"x3 3/8"x29" (24x86x738)
(x1)
H29
WALL RAIL - W4L18636
1"x3 3/8"x14 1/8" (24x86x360)
(x1)
H77
ATTACHMENT BOARD - W4L18557
1"x3 3/8"x20 1/8" (24x86x512)
(x1)
L01
FLOOR BOARD - W4L18581
5/8"x4 1/4"x21 1/4" (16x107x540)
(x2)
Wood Components (Not to Scale)
H23
WALL RAIL - W4L18626
(x2) 1"x3 3/8"x54 3/4" (24x86x1390)
H24
WALL BOARD - W4L18627
1"x3 3/8"x50 1/8" (24x86x1274)
(x1)
J02
WALL RAIL - W4L18568
(x2) 1"x2 3/8"x58 3/8" (24x60x1483)
J03
WALL RAIL - W4L18594
1"x2 3/8"x55 3/8" (24x60x1407)
(x2)
K01
WALL RAIL - W4L18577
5/8"x5 1/4"x52 3/4" (16x134x1340)
(x1)
K02
WALL RAIL - W4L18578
5/8"x5 1/4"x53 3/8" (16x134x1356)
(x1)
K03
WALL RAIL - W4L18595
5/8"x5 1/4"x54 3/4" (16x134x1390)
(x1)
L03
FLOOR BOARD - W4L18583
5/8"x4 1/4"x54 5/8" (16x107x1389)
(x1)
H26
WALL RAIL - W4L18629
1"x3 3/8"x28 1/8" (24x86x713)
(x1)
H28
WALL RAIL - W4L18562
1"x3 3/8"x13 1/4" (24x86x336)
(x1)
H76
LADDER RUNG - W4L18556
1"x3 3/8"x18 1/8" (24x86x460)
(x4)
J01
WALL RAIL - W4L18559
1"x2 3/8"x25 1/4" (24x60x642)
(x4)
L02
FLOOR BOARD - W4L18582
5/8"x4 1/4"x54 5/8" (16x107x1389)
(x1)
