Backyard Discovery TIMBER CROSSING Manual page 71

STEP 32 - FORT ASSEMBLY
1 3/4 in
[43 mm]
H28
WALL RAIL - W4L18562
1"x3 3/8"x13 1/4" (24x86x336)
(x1)
198
WASHER - 8x19
197
LAG SCREW - 2 1/2"
H29
1 3/4 in
[43 mm]
H29
WALL RAIL - W4L18636
1"x3 3/8"x14 1/8" (24x86x360)
(x1)
(x2)
(x2)
(x1)
1 3/4 in
[43 mm]
PART
QTY
NUMBER
2 H100197
2 H100198
H28
(x1)
71
DESCRIPTION
LAG SCREW WH 5/16x2-1/2 BLK
WASHER LOCK EXT 8x19 BLK
