Summary of Contents for Backyard Discovery RIVERTON 2200098

  • Page 1 RIVERTON MANUFACTURED BY: Wooden Swing Set Backyard Discovery 3305 Airport Drive Pittsburg, KS 66762 Model # 2200098 Owner's Manual & Assembly Instructions 800-856-4445 average 2 person assembly time assembly time may vary based on skill level For the most up to date assembly manual, to register your set, or to order replacement parts please visit www.backyarddiscovery.com...
  • Page 2 INSTALLATION SERVICES AVAILABLE! Need a helping hand? Let our team of professionals handle the installation for you! *Installation services are only available to U.S. customers. With Go Configure, we bring you 18 years of experience right to your doorstep. We service a wide array of indoor and outdoor recreation products that most consumers don’t have the time or ability to deliver &...
  • Page 3 Owner’s Manual Please Read This Before Starting Assembly MISSING A PART? CALL US BEFORE GOING BACK TO THE STORE Th e store where you made your purchase does not stock parts for this item. If you have assembly questions or you are missing or have damaged parts, please call 1-800-856-4445 you can also visit www.backyarddiscovery.com...
  • Page 4 All wood carries a five (5) year warranty against rot and decay from the original purchase date. Backyard Discovery Metal Play Structure Backyard Discovery warrants this metal play product to be free from defects in materials and workmanship for a period of five (5) years from the original date of purchase. General Warranty Information This warranty applies to the original owner and registrant and is non-transferable.
  • Page 5 Owner’s Manual Operating Instructions and Safety Warnings WARNING: BURN HAZARD • Pay special attention to plastic and metal surfaces as they may be hot enough to cause burns. • Always check the temperature of the product before NOTE: letting your children play on it. •...
  • Page 6 Owner’s Manual Please Read This Before Starting Assembly Positioning Your Playcenter Suggested Playground Surfacing • Th e playcenter is designed to be installed on a level • Do not install home playground equipment over surface by an adult with an adult helper. Place concrete, asphalt, packed earth, grass, carpet, or any in a fl at area of your yard to minimize ground other hard surface.
  • Page 7 Owner’s Manual Please Read This Before Starting Assembly APPENDIX A The following information is from the United States X3.1.3.2 Do not install loose-fi ll surfacing over hard surfaces such as concrete or asphalt. Consumer Product Safety Commission’s Information X3.1.4 Poured-In-Place Surfaces or Pre-Manufactured Sheet for playground surfacing material;...
  • Page 8 • Check all moving parts including swing seats, Backyard Discovery assumes no responsibility or ropes, cables, and chains for wear, rust, or other liability for any charge incurred by the Customer for deterioration.
  • Page 9 About Our Wood Backyard Discovery uses 100% Cedar (C. Lanceolata) wood. Although we take great care in selecting the best quality lumber available, wood is still a product of nature and susceptible to weathering which can change the appearance of your set.
  • Page 10 Owner’s Manual Assembly Tips Protrusion Hazard Incorrect Correct If you see exposed threads and your bolt protrudes beyond the T-Nut you may have over tightened the bolt or used incorrect hardware. If you’ve overtightened, remove the bolt and add washers to eliminate the protrusion.
  • Page 11 Owner’s Manual Assembly Tips ASSEMBLY TIP: Keep an eye out for these boxes which will contain helpful pictures and information making the assembly process as quick and painless as possible. Sorting Wood When removing the wood from the boxes we recommend arranging them by part number before you begin assembly.
  • Page 12 Owner's Manual Basic Setup Dimensions & Assembly Notes Place the set on level ground, not less than 6'-7" [2 m] from any structure or obstruction such as a fence, garage, house, overhanging branches, laundry lines, or electrical wires. • While assembling unit, take time before and after each phase to make sure fort is level. If fort is not level, assembly will be difficult and improper assembly may result.
  • Page 13 Owner's Manual Tools Required for Installation...
  • Page 14 Parts Identification Owner's Manual Wood Components (Not to Scale) LOWER UPRIGHT - W4L16118 1 3/8"x3 3/8"x42 3/4" (36x86x1087) (x1) UPPER UPRIGHT - W4L15659 1 3/8"x3 3/8"x38 7/8" (36x86x989) (x1) LOWER UPRIGHT - W2A03289 1 3/8"x3 3/8"x42 3/4" (36x86x1087) (x1) UPPER UPRIGHT - W4L07298 1 3/8"x3 3/8"x38 7/8"...
  • Page 15 Parts Identification Owner's Manual Wood Components (Not to Scale) DECK BRACE - W4L07276 (x2) 1"x3 3/8"x13 3/4" (24x86x350) BENCH GROUND BOARD - W4L07282 1"x3 3/8"x16 7/8" (24x86x430) (x2) BENCH UPRIGHT - W4L07284 (x2) 1"x3 3/8"x11 3/4" (24x86x300) BENCH SEAT SUPPORT - W4L07283 1"x3 3/8"x6 1/2"...
  • Page 16 Parts Identification Owner's Manual Wood Components (Not to Scale) LADDER RAIL - W4L07268 1"x2 3/8"x46 3/8" (24x60x1177) (x1) SHELF SUPPORT - W4L07058 1"x2 3/8"x3 3/8" (24x60x86) (x2) SERVING SHELF - W4L07271 5/8"x5 1/4"x35 3/8" (16x134x898) (x1) WALL BOARD - W4L07316 5/8"x5 1/4"x20 1/8"...
  • Page 17 Parts Identification Owner's Manual Wood Components (Not to Scale) GROUND BOARD - W4L07286 5/8"x3 3/8"x37 1/2" (16x86x951) (x1) FLOOR RAIL - W4L07275 5/8"x3 3/8"x37 1/4" (16x86x946) (x1) TARP SUPPORT - W4L15033 5/8"x3 3/8"x37 3/4" (16x86x959) (x2) ROOF BOARD - W4L15026 5/8"x3 3/8"x27 7/8"...
  • Page 18 Parts Identification Owner's Manual Wood Components (Not to Scale) SAFETY BOARD - W4L07041 5/8"x2 3/8"x35 3/8" (16x60x898) (x3) SAFETY BOARD - W4L07263 5/8"x2 3/8"x37 1/2" (16x60x951) (x1) PICKET - W4L07301 5/8"x2 3/8"x18 3/8" (16x60x466) (x9) AWNING BOARD - W4L15020 5/8"x2 3/8"x28 5/8" (16x60x726) (x1) PICKET - W4L07517 5/8"x1 3/8"x18 3/8"...
  • Page 19 Owner's Manual Parts Identification Hardware Components H100165 BOLT WH H100115 BOLT WH (X2) 5/16x5 1/4 (X24) 5/16x1/2 H100008 H100166 BOLT WH BOLT WH (X4) (X2) 5/16x1 5/16x4-1/4 H100009 H100018 BOLT WH BOLT WH (X18) (X2) 5/16x1 1/4 5/16x3 1/2 H100014 BOLT WH H100028 LAG SCREW WH...
  • Page 20 Owner's Manual Parts Identification Hardware Components A100041 TORX WRENCH (x1) T-40 H100147 TORX BIT A100042 TORX BIT (x1) T-30 (x1) T-40 H100114 TORX WRENCH (x1) T-30 H100072 T-NUT (x23) H100005 NUT BARREL H100030 WASHER LOCK (x19) (x115) 5/16x7/8 8x19 H100074 T-NUT (x115) 5/16...

  • Page 21: Table Of Contents

    Owner's Manual Parts Identification Hardware Components H100047 BOLT HEX (x2) 5/16x2 3/4 H100090 SCREW PFH H100042 BOLT HEX (x33) 8x2 1/2" (x4) 5/16x1 1/4 H100111 SCREW PFH H100062 BOLT PTH (x4) (x2) 1/4x1 1/4 H100089 SCREW PFH H100063 BOLT PTH (x9) 8x1 3/4 (x11)
  • Page 22 Owner's Manual Parts Identification Accessory Components (Not to Scale) A100158 L BRACKET (x2) 54x67 SWING BEAM A100078 SWING BEAM CLOCK A4M00511 (x1) A4M00512 EXT. BRACKET (x1) EXT BRACKET (x1) BLUE - LEFT BLUE - RIGHT 90° L-BRACKET - A4M00555 L BRACKET A100153 (x10) (x2)
  • Page 23 Owner's Manual Parts Identification Accessory Components (Not to Scale) A6P00178 A6P00176 SLIDE RAIL TOP RIGHT SLIDE RAIL TOP LEFT (x1) (x1) A6P00179 A6P00177 SLIDE RAIL BOTTOM LEFT SLIDE RAIL BOTTOM RIGHT (x1) (x1) CHAIN BLUE A4M00524 (x4) 51.25" A4M00525 CHAIN BLUE 31" (x2) A4M00704 CHALKBOARD...
  • Page 24 BENCH STEP 1 ASSEMBLY H100115 BOLT WH H100005 NUT BARREL (x2) 5/16x1/2 (x2) 5/16x7/8 BENCH GROUND BOARD - W4L07282 A100158 L BRACKET 54x67 1"x3 3/8"x16 7/8" (24x86x430) (x2) (x2) H100031 WASHER LOCK (x2) 12x19 (x2) WASHER - 12x19 (x2) NUT BARREL - 7/8" (x2) L BRACKET 54x67 (x2)

  • Page 25: (X4) 5/16X1

    BENCH STEP 2 ASSEMBLY H100011 BOLT WH (x4) 5/16x1 3/4 H100074 T-NUT (x4) 5/16 BENCH UPRIGHT - W4L07284 1"x3 3/8"x11 3/4" (24x86x300) (x2) H100030 WASHER LOCK (x4) 8x19 (x1) (x1) (x4) T-NUT - 5/16" (x4) BOLT - 1 3/4" (x4) WASHER - 8x19...
  • Page 26 BENCH STEP 3 ASSEMBLY H100011 BOLT WH (x4) 5/16x1 3/4 H100074 T-NUT (x4) 5/16 BENCH SEAT SUPPORT - W4L07283 1"x3 3/8"x6 1/2" (24x86x166) (x2) H100030 WASHER LOCK (x4) 8x19 (x4) BOLT - 1 3/4" (x4) WASHER - 8x19 (x4) T-NUT - 5/16" (x1) (x1)
  • Page 27 BENCH STEP 4 ASSEMBLY H100089 SCREW PFH (x8) 8x1 3/4 BENCH SEAT - W4L07098 5/8"x3 3/8"x23 1/2" (16x86x598) (x2) TIP: PRE-DRILL H09 USING A 1/8" DRILL BIT AND M18 AS THE TEMPLATE, CENTER AND PRE-DRILL PILOT HOLES ON H09 BOARDS. (x8) SCREW - 1 3/4"...

  • Page 28: H100143 Bolt Wh

    SWING BEAM STEP 1 ASSEMBLY SWING BEAM - W4L07244 (x1) 5 1/4"x2"x46" (134x50x1168) SWING BEAM A4M00696 JOINT BRACKET (x1) SWING BEAM - W4L07243 BLUE (x1) 5 1/4"x2"x46" (134x50x1168) H100165 BOLT WH H100143 BOLT WH H100140 NUT BARREL (x2) 5/16x5 1/4 H100074 T-NUT (x4)
  • Page 29 SWING BEAM STEP 2 ASSEMBLY H100047 BOLT HEX L BRACKET A100153 (x2) 5/16x2 3/4 H100110 NUT LOCK H100105 WASHER FLAT (x2) 66x66x127 BLUE (x2) 5/16 (x4) 8x27 SWING BEAM SWING BEAM A4M00512 A4M00511 EXT BRACKET EXT. BRACKET (x1) (x1) H100011 BOLT WH BLUE - RIGHT BLUE - LEFT...
  • Page 30 SWING BEAM STEP 3 ASSEMBLY H100105 WASHER FLAT (x6) 8x27 H100099 SWING (x6) HANGER H100110 NUT LOCK H100103 WASHER 5/16x9 1/2 (x6) 5/16 (x4) SAFETY 17x30 (x6) NUT - 5/16" (x6) WASHER - 8x27 (x4) WASHER - 17x30 (x6) SWING HANGER - 9 1/2"...

  • Page 31: Bolt Wh

    SWING BEAM STEP 4 ASSEMBLY ANGLE BRACE - W4L15708 1 3/8"x3 3/8"x36 7/8" (36x86x936) (x2) A4M01174 A-FRAME (x1) BRACKET SWING BEAM SUPPORT - W4L15705 (x1) 2"x3 3/8"x44 3/4" (50x86x1136) H100009 BOLT WH H100018 BOLT WH (x4) 5/16x1 1/4 (x2) 5/16x3 1/2 H100074 T-NUT (x6)
  • Page 32 SWING BEAM STEP 5 ASSEMBLY GROUND BOARD - W4L15709 H100008 BOLT WH H100013 BOLT WH (x2) 1"x3 3/8"x41 1/2" (24x86x1053) (x2) 5/16x1 (x4) 5/16x2 1/4 ANGLE BRACE - W4L15707 H100030 WASHER LOCK H100074 T-NUT 1 3/8"x3 3/8"x45 7/8" (36x86x1166) (x2) (x6) (x6) 5/16...
  • Page 33 SWING BEAM STEP 6 ASSEMBLY H100166 BOLT WH H100013 BOLT WH END SUPPORT - W4L15706 (x2) 5/16x4-1/4 (x4) 5/16x2 1/4 (x1) 1"x3 1/2"x40" (24x86x1013) H100009 BOLT WH METAL A4M00938 H100030 WASHER LOCK (x4) 5/16x1 1/4 L-BRACKET - (x2) (x2) BLUE 8x19 NOTE: FULLY TIGHTEN HARDWARE NOW...
  • Page 34 SWING BEAM STEP 7 ASSEMBLY (x1) SWING BEAM ASSEMBLY H100011 BOLT WH H100005 NUT BARREL (x2) 5/16x1 3/4 (x2) 5/16x7/8 (x1) A-FRAME ASSEMBLY NOTE: FULLY TIGHTEN ALL HARDWARE NOW SWING BEAM ASSEMBLY (x1) (x2) NUT BARREL - 7/8" (x2) BOLT - 1 3/4" A-FRAME ASSEMBLY (x1)
  • Page 35 SLIDE ASSEMBLY STEP 1 SLIDE BRACE - W4L15702 5/8"x3 3/8"x14 1/4" (16x86x362) (x1) A6P00358 SLIDE BED BLUE (x1) H100074 T-NUT H100115 BOLT WH (x2) 5/16 (x2) 5/16x1/2 NOTE: TAKE NOTE OF SLIDE BED SURFACE FINISH, THE DULL SIDE WILL BE TOWARDS THE GROUND. PLACE SLIDE BRACE CENTERED ON THE BOTTOM (DULL SIDE) AND 1/2"...
  • Page 36 SLIDE ASSEMBLY STEP 2 A6P00176 A6P00177 SLIDE RAIL TOP LEFT SLIDE RAIL BOTTOM LEFT (x1) (x1) A6P00178 A6P00179 SLIDE RAIL TOP RIGHT SLIDE RAIL BOTTOM RIGHT (x1) (x1) H100005 NUT BARREL WH H100115 BOLT WH (x8) 5/16x7/8 (x8) 5/16x1/2 NOTE: REPEAT ON OTHER SIDE, MAKING A LEFT AND RIGHT ASSEMBLY.
  • Page 37 SLIDE ASSEMBLY STEP 3 CENTER SLIDE BRACE - W4L15703 5/8"x3 3/8"x14 1/4" (16x86x362) (x2) NOTE: PLACE (1) SLIDE RAIL ASSEMBLY ON A FLAT SURFACE AND BEGIN INSERTING SLIDE BED AT THE BOTTOM OF THE SLIDE RAIL (FIGURE 1). HAVE A HELPER BEND THE SLIDE BED TOWARDS THE TOP OF THE SLIDE AND INSERT THE BED INTO THE SLIDE CAVITY.
  • Page 38 SLIDE ASSEMBLY STEP 4 NOTE: PLACE SECOND SLIDE RAIL ASSEMBLY OVER THE TOP OF THE SLIDE BED AND M78 CENTER SLIDE BRACES. INSERT THE SLIDE BED AND CENTER SLIDE BRACES INTO THE SLIDE CAVITY. MAKE SURE SLIDE BED IS COMPLETELY IN THE SLIDE CAVITY. FAILURE TO INSERT SLIDE BED COMPLETELY AND SECURED MAY RESULT IN INJURY OR AMPUTATION.
  • Page 39 SLIDE ASSEMBLY STEP 5 H100090 SCREW PFH (x24) 8x2 1/2" NOTE: USING AN 1/8" DRILL BIT, DRILL PILOT HOLES IN EACH INDENTATION ALONG EACH SIDE RAIL. THERE SHOULD BE 12 INDENTATIONS ON EACH RAIL. BE SURE TO DRILL THROUGH THE SLIDE RAIL AND THE SLIDE BED. THEN SECURE WITH THE PROVIDED HARDWARE.
  • Page 40 STEP 1A FORT ASSEMBLY FLOOR RAIL - W4L07254 GROUND BOARD - W4L07299 GROUND BOARD - W4L15031 (x1) 5/8"x3 3/8"x37 1/4" (16x86x946) (x1) 5/8"x3 3/8"x31 5/8" (16x86x802) (x1) 5/8"x3 3/8"x31 5/8" (16x86x802) LOWER UPRIGHT - W4L16117 LOWER UPRIGHT - W4L16116 1 3/8"x3 3/8"x42 3/4" (36x86x1087) 1 3/8"x3 3/8"x42 3/4"...

  • Page 41: (X4) 8X1

    STEP 1B FORT ASSEMBLY WALL RAIL - W4L07267 WALL BOARD - W4L07316 1"x3 3/8"x35 3/8" (24x86x898) (x1) 5/8"x5 1/4"x20 1/8" (16x134x510) (x1) H100087 SCREW PFH H100013 BOLT WH H100009 BOLT WH H100074 T-NUT (x2) 8x1 1/4 (x4) (x4) 5/16x2 1/4 5/16x1 1/4 H100030 WASHER LOCK...

  • Page 42: H100090 Screw Pfh

    FORT ASSEMBLY STEP 2 H100090 SCREW PFH (x2) 8x2 1/2" SHELF SUPPORT - W4L07058 SERVING SHELF - W4L07271 1"x2 3/8"x3 3/8" (24x60x86) (x2) 5/8"x5 1/4"x35 3/8" (16x134x898) (x1) H100086 SCREW PFH (x6) 8x1 1/2 SIDE VIEW (x6) SCREW - 1 1/2" (x2) SCREW - 2 1/2"...

  • Page 43: (X9) 8X1

    STEP 3 FORT ASSEMBLY H100088 SCREW PFH PICKET - W4L07056 WALL BOARD - W4L07302 (x16) 8x1 1/8 5/8"x1 3/8"x19 5/8" (16x34x500) (x2) 5/8"x3 3/8"x19 5/8" (16x86x500) (x6) (x8) SCREW - 1 1/8" (x1) (x1) (x8) SCREW - 1 1/8" (x3) (x3)
  • Page 44 STEP 4 FORT ASSEMBLY FLOOR RAIL - W4L07275 GROUND BOARD - W4L15021 LOWER UPRIGHT - W2A03289 5/8"x3 3/8"x37 1/4" (16x86x946) 5/8"x3 3/8"x23 1/4" (16x86x591) (x1) (x1) (x1) 1 3/8"x3 3/8"x42 3/4" (36x86x1087) LOWER UPRIGHT - W4L16118 GROUND BOARD - W4L15030 GROUND BOARD - W4L15022 (x1) 1 3/8"x3 3/8"x42 3/4"...
  • Page 45 STEP 5 FORT ASSEMBLY SAFETY BOARD - W4L07041 DECK BRACE - W4L07273 H100012 BOLT WH H100010 BOLT WH 5/8"x2 3/8"x35 3/8" (16x60x898) (x1) (x2) 1"x3 3/8"x18 3/4" (24x86x476) (x2) (x2) 5/16x2 5/16x1-1/2 H100145 LAG SCREW H100074 T-NUT (x2) (x4) 5/16 1/4x1 1/2 H100138 WASHER LOCK...
  • Page 46 STEP 6 FORT ASSEMBLY GROUND BOARD - W4L07252 H100030 WASHER LOCK 5/8"x3 3/8"x36 1/8" (16x86x919) (x2) H100026 LAG SCREW (x4) (x4) 8x19 5/16x1 1/2 (x1) (x1) (x4) WASHER - 8x19 (x4) LAG SCREW - 1 1/2"...
  • Page 47 FORT ASSEMBLY STEP 7A LADDER RAIL - W4L15023 GROUND BOARD - W4L07286 1"x2 3/8"x46 3/8" (24x60x1177) (x1) 5/8"x3 3/8"x37 1/2" (16x86x951) (x1) 90° L-BRACKET - A4M00555 (x1) FLOOR RAIL - W4L07297 1"x3 3/8"x36 1/8" (24x86x919) (x1) H100028 LAG SCREW H100145 LAG SCREW H100027 LAG SCREW...
  • Page 48 FORT ASSEMBLY STEP 7B LADDER RAIL - W4L07265 (x1) 1"x2 3/8"x46 3/8" (24x60x1177) H100010 BOLT WH H100008 BOLT WH H100074 T-NUT H100030 WASHER LOCK (x1) (x2) 5/16x1-1/2 5/16x1 (x3) 5/16 (x3) 8x19 (x2) T-NUT - 5/16" (x2) WASHER - 8x19 (x2) BOLT - 5/16x1"...
  • Page 49 STEP 8 FORT ASSEMBLY LADDER RAIL - W4L07287 LADDER RAIL - W4L07268 FLOOR RAIL - W4L07251 1"x2 3/8"x46 3/8" (24x60x1177) 1"x2 3/8"x46 3/8" (24x60x1177) (x1) (x1) (x1) 1"x3 3/8"x36 1/8" (24x86x919) H100138 WASHER LOCK H100028 LAG SCREW H100145 LAG SCREW H100030 WASHER LOCK (x2)
  • Page 50 STEP 9 FORT ASSEMBLY DECK BRACE - W4L07273 FLOOR SUPPORT - W4L07255 (x2) 1"x3 3/8"x18 3/4" (24x86x476) (x1) 1"x3 3/8"x36 1/8" (24x86x919) H100090 SCREW PFH H100011 BOLT WH (x4) 8x2 1/2" H100074 T-NUT (x2) H100030 WASHER LOCK H100145 LAG SCREW H100138 WASHER LOCK 5/16x1 3/4...
  • Page 51 STEP 1 0 FORT ASSEMBLY UPPER UPRIGHT - W4L15658 UPPER UPRIGHT - W4L15659 1 3/8"x3 3/8"x38 7/8" (36x86x989) 1 3/8"x3 3/8"x38 7/8" (36x86x989) (x1) (x1) UPPER UPRIGHT - W4L07307 UPPER UPRIGHT - W4L07298 1 3/8"x3 3/8"x38 7/8" (36x86x989) 1 3/8"x3 3/8"x38 7/8" (36x86x989) (x1) (x1) H100028...

  • Page 52: H100086 Screw Pfh

    STEP 1 1 FORT ASSEMBLY H100086 SCREW PFH (x32) 8x1 1/2 FLOOR BOARD - W4L12364 5/8"x3 3/8"x37 1/4" (16x86x946) (x1) H100087 SCREW PFH (x1) 8x1 1/4 FLOOR PANEL - W2A02023 1 1/4"x17"x37 1/4" (32x432x946) (x2) 1'-4" [407 mm] (x2) SCREW 8x1-1/4" HERE (x1) NOTE HOLE (x32)
  • Page 53 STEP 1 2 FORT ASSEMBLY ROOF SUPPORT - W4L15027 ROOF BOARD - W4L15026 HOLE GOES UPWARD 1"x3 3/8"x29 1/2" (24x86x748) 5/8"x3 3/8"x27 7/8" (16x86x709) (x1) (x2) H100012 BOLT WH H100010 BOLT WH H100074 T-NUT H100030 WASHER LOCK (x4) (x4) 5/16x2 5/16x1-1/2 (x8) 5/16...
  • Page 54 STEP 13 FORT ASSEMBLY HOLES UPWARD HOLE GOES UPWARD WALL RAIL - W4L15024 ROOF SUPPORT - W4L15027 ROOF BOARD - W4L15025 1"x3 3/8"x29 1/2" (24x86x748) 1"x3 3/8"x27 7/8" (24x86x709) 1"x3 3/8"x35 3/8" (24x86x898) (x1) (x2) (x1) H100011 BOLT WH H100013 BOLT WH H100074 T-NUT...
  • Page 55 STEP 14 FORT ASSEMBLY WALL BOARD - W4L07269 WALL BOARD - W4L07315 H100027 LAG SCREW 5/8"x3 3/8"x36 1/8" (16x86x919) 5/8"x3 3/8"x36 1/8" (16x86x919) (x1) (x1) (x4) 5/16x2 1'-5 1/2" 1'-6 3/4" [443 mm] [476 mm] H100030 WASHER LOCK (x4) 8x19 NOTE HOLE LOCATION (x4)
  • Page 56 STEP 15 FORT ASSEMBLY DECK BRACE - W4L07276 H100011 BOLT WH H100145 LAG SCREW (x2) 1"x3 3/8"x13 3/4" (24x86x350) H100074 T-NUT (x4) 5/16x1 3/4 (x2) (x4) 5/16 1/4x1 1/2 H100030 WASHER LOCK H100138 WASHER LOCK (x4) (x2) 8x19 6x15 (x1) (x1) (x4) WASHER - 8x19...
  • Page 57 FORT ASSEMBLY STEP 16 HOLES UPWARD A4M00555 90° L-BRACKET - (x6) TARP SUPPORT - W4L15033 TARP SUPPORT - W4L15028 (x2) 5/8"x3 3/8"x37 3/4" (16x86x959) (x1) 5/8"x3 3/8"x36 1/8" (16x86x919) H100490 H100141 BOLT WH BOLT WH H100136 NUT BARREL H100072 T-NUT H100139 WASHER LOCK (x2)
  • Page 58 FORT ASSEMBLY STEP 17 H100128 SCREW PWH (x6) 8x5/8 A6P00497 FORT TARP (x1) (x1) FORT TARP (x6) SCREW - 5/8...
  • Page 59 STEP 18 FORT ASSEMBLY SAFETY BOARD - W4L07041 H100012 BOLT WH WALL RAIL - W4L07306 H100074 T-NUT 5/8"x2 3/8"x35 3/8" (16x60x898) (x4) (x1) 5/16x2 (x1) 5/8"x3 3/8"x35 3/8" (16x86x898) (x4) 5/16 H100030 WASHER LOCK (x4) 8x19 (x1) (x4) T-NUT - 5/16" (x4) WASHER - 8x19 (x1)
  • Page 60 STEP 19 FORT ASSEMBLY SAFETY BOARD - W4L07263 H100027 LAG SCREW WALL RAIL - W4L07309 H100030 WASHER LOCK (x4) (x1) 5/8"x2 3/8"x37 1/2" (16x60x951) 5/8"x3 3/8"x37 1/2" (16x86x951) (x1) (x4) 5/16x2 8x19 (x4) WASHER - 8x19 (x4) LAG SCREW - 2" (x1) (x1)

  • Page 61: H100088 Screw Pfh

    FORT ASSEMBLY STEP 20 SAFETY BOARD - W4L07093 SAFETY BOARD - W4L07041 WALL RAIL - W4L07306 (x1) 5/8"x1 3/8"x35 3/8" (16x34x898) 5/8"x2 3/8"x35 3/8" (16x60x898) (x1) (x1) 5/8"x3 3/8"x35 3/8" (16x86x898) H100012 BOLT WH H100088 SCREW PFH H100074 T-NUT H100030 WASHER LOCK (x2) (x4)
  • Page 62 STEP 21 FORT ASSEMBLY WALL BOARD - W4L07288 90° L-BRACKET - A4M00555 H100072 T-NUT 1"x2 3/8"x36 5/8" (24x60x930) (x1) (x1) (x1) H100490 BOLT WH H100136 NUT BARREL H100139 WASHER LOCK H100030 WASHER LOCK H100010 BOLT WH H100074 T-NUT (x2) 1/4x5/8 (x1) (x1) (x1)

  • Page 63: (X64) 8X1

    STEP 22 FORT ASSEMBLY PICKET - W4L07517 H100088 SCREW PFH WALL BOARD - W4L07314 5/8"x1 3/8"x18 3/8" (16x34x466) (x2) WALL BOARD - W4L07303 (x20) 8x1 1/8 5/8"x3 3/8"x18 3/8" (16x86x466) (x6) (x1) 5/8"x5 1/4"x18 3/8" (16x134x466) EVENLY SPACED 7/8" [22 mm] (x3) (x1) (x3)
  • Page 64 STEP 23 FORT ASSEMBLY PICKET - W4L07301 H100088 SCREW PFH 5/8"x2 3/8"x18 3/8" (16x60x466) (x3) (x6) 8x1 1/8 2 1/8" (3 SPACES) [53 mm] 7/8" [22 mm] (x3) (x6) SCREW - 1 1/8"...
  • Page 65 FORT ASSEMBLY STEP 24 PICKET - W4L07301 H100088 SCREW PFH (x6) 5/8"x2 3/8"x18 3/8" (16x60x466) (x12) 8x1 1/8 7/8" [22 mm] 2" [52 mm] (7 SPCS) (x6) (x12) SCREW - 1 1/8"...
  • Page 66 STEP 25 FORT ASSEMBLY 2 1/8" [53 mm] A4M00704 CHALKBOARD (x1) 3/8" H100207 SCREW PWH (x4) [11 mm] 8x1 1/2 (x1) CHALKBOARD (x4) SCREW - 1 1/2"...
  • Page 67 FORT ASSEMBLY STEP 26 H100086 SCREW PFH (x4) 8x1 1/2 ATTACHMENT BOARD - W4L07518 1"x1 3/8"x4 3/4" (24x34x120) (x1) H100128 SCREW PWH A6P00499 A100078 TELESCOPE (x2) 8x5/8 (x1) CLOCK (x1) (x1) (x1) TELESCOPE CLOCK (x2) SCREW - 5/8 (x4) SCREW - 1 1/2" (x1) FLUSH TOP WITH SIDE RAIL...
  • Page 68 STEP 27 FORT ASSEMBLY H100081 SCREW H100072 T-NUT H100062 BOLT PTH (x2) (x2) TAPPING (x2) 1/4x1 1/4 14x2 A6P00314 HAND GRIP BLUE PLASTIC (x2) H100106 WASHER FLAT (x4) 9x18 H100108 WASHER LOCK (x4) 8x15 (x2) WASHER - 9x18 (x2) WASHER - 8x15 (x2) SCREW - 14x2"...
  • Page 69 STEP 28A FORT ASSEMBLY AWNING BOARD - W4L15019 AWNING SUPPORT - W4L06908 (x2) 1"x2 3/8"x14 1/8" (24x60x358) (x2) 1"x2 3/8"x11 3/4" (24x60x298) H100027 LAG SCREW H100145 LAG SCREW (x4) (x2) 5/16x2 1/4x1 1/2 H100138 WASHER LOCK H100030 WASHER LOCK (x2) (x4) 6x15 8x19...
  • Page 70 STEP 28B FORT ASSEMBLY SAFETY BOARD - W4L12369 H100490 BOLT WH H100136 NUT BARREL H100139 WASHER LOCK 1"x1 3/8"x15 1/2" (24x34x394) (x2) (x2) 1/4x5/8 (x2) (x2) 1/4x5/8 8x15 H100111 SCREW PFH A4M00555 90° L-BRACKET - BLK (x4) (x2) (x2) SCREW - 2" (x1) (x2) SCREW - 2"...
  • Page 71 FORT ASSEMBLY STEP 29A H100088 SCREW PFH (x4) 8x1 1/8 AWNING BOARD - W4L07053 (x1) 5/8"x1 3/8"x26 5/8" (16x34x676) A6P00498 TARP AWNING (x1) (x4) (x1) SCREW - 1 1/8" (x1) TARP AWNING GROMMETS THIS SIDE TOP EDGE OF AWNING GOES BETWEEN THE N1 AND O4 BOARDS.
  • Page 72 STEP 29B FORT ASSEMBLY AWNING BOARD - W4L15020 H100072 T-NUT H100128 SCREW PWH H100490 BOLT WH 5/8"x2 3/8"x28 5/8" (16x60x726) (x2) (x1) (x2) 8x5/8 (x2) 1/4x5/8 INSIDE VIEW TIP: INSTALL T-NUTS IN WOOD FIRST (x1) (x2) T-NUT - 1/4" BOTTOM EDGE OF AWNING WRAPS THE N7 BOARD. (x2) SCREW - 5/8 (x2)
  • Page 73 STEP 30 FORT ASSEMBLY H100072 T-NUT H100087 SCREW PFH LADDER RUNG - W4L15032 LADDER RUNG - W4L07520 (x10) (x24) 8x1 1/4 (x5) 5/8"x3 3/8"x19 1/4" (16x86x489) (x1) 5/8"x3 3/8"x19 1/4" (16x86x489) T-NUT 1/4 (x5) (10 PLCS) ON BACK OF BOARD (x5) ASSEMBLY (x24)
  • Page 74 FORT ASSEMBLY STEP 31 A6P00041 H100063 BOLT PTH H100108 WASHER LOCK A6P00040 BLUE HC ROCK #1 (x2) BLUE HC ROCK #2 (x3) (x10) 1/4x3/4 (x10) 8x15 (x10) WASHER - 8x15 (x10) BOLT - 3/4" (x2) BLUE HC ROCK #1 (x3) BLUE HC ROCK #2...
  • Page 75 STEP 32 FORT ASSEMBLY (1) BENCH ASSEMBLY H100115 BOLT WH (x2) 5/16x1/2 (x2) BOLT - 1/2" BENCH ASSEMBLY (x1)
  • Page 76 STEP 33 FORT ASSEMBLY H100128 SCREW PWH (x2) 8x5/8 A100314 "A" REVISION TAG (x1) (x1) "A" REVISION TAG (x2) SCREW - 5/8...
  • Page 77 STEP 34 FORT ASSEMBLY H100095 WASHER SPLIT H100042 BOLT HEX (x4) 5/16 (x4) 5/16x1 1/4 H100074 T-NUT H100105 WASHER FLAT (x4) 5/16 (1) SWING BEAM ASSEMBLY (x4) 8x27 (x4) WASHER - 8x27 (x4) (x4) WASHER - 5/16" T-NUT - 5/16" (x4) BOLT HEX - 1 1/4"...
  • Page 78 STEP 35 FORT ASSEMBLY A4M00524 CHAIN BLUE 51.25" (x4) A4M00525 CHAIN BLUE 31" (x2) A6P00034 TRAPEZE YELLOW A100069 A6P00133 (x1) QUICK LINK SWING SEAT BLUE 22" (x6) (x2) TIGHTEN QUICK LINK INSERT CHAIN INTO QUICK LINK (x2) (x4) CHAIN BLUE 31" CHAIN BLUE 51.25"...
  • Page 79 FORT ASSEMBLY STEP 36 T-NUT H100074 H100115 BOLT WH (x2) 5/16 (x2) 5/16x1/2 (1) SLIDE ASSEMBLY 5 1/2" 5 7/8" [141 mm] [148 mm] 2" [50 mm] 4 1/8" [106 mm] CENTER SLIDE IN OPENING, DRILL (2) 3/8 INCH HOLES THRU SLIDE BED &...
  • Page 80 STEP 37 FORT ASSEMBLY A4M00527 GROUND STAKE REBAR (x3) H100031 WASHER LOCK H100115 BOLT WH H100005 NUT BARREL (x2) (x2) (x2) 5/16x1/2 12x19 5/16x7/8 TAP IN GROUND STAKES AT AN APPROXIMATE 45° ANGLE AT THE LOCATIONS SHOWN. USING GROUND STAKES AS A GUIDE, DRILL 7/16" DIA HOLES. NOTE: FAILURE TO USE GROUND STAKES CAN VOID WARRANTY &...
  • Page 81 FORT ASSEMBLY STEP 38 A4M00527 GROUND STAKE REBAR (x4) H100031 WASHER LOCK H100115 BOLT WH H100004 NUT BARREL (x4) (x4) (x4) 5/16x1/2 12x19 5/16 x 5/8 TAP IN GROUND STAKES AT AN APPROXIMATE 45° ANGLE AT THE LOCATIONS SHOWN. USING GROUND STAKES AS A GUIDE, DRILL 7/16" DIA HOLES. NOTE: FAILURE TO USE GROUND STAKES CAN VOID WARRANTY &...
