Backyard Discovery TIMBER CROSSING Manual page 11

Owner's Manual - Parts Identification
H101170 BOLT HEX BLK
(x12) 3/8x5 3/4
H100476
BOLT HEX BLK
(x2)
5/16x4 1/4
H101171 BOLT HEX BLK
(x4) 3/8x3 1/4
H100362
SCREW PFH BLK
(x8)
8x3
H100201
SCREW PFH BLK
(x16)
8x2-1/2
H100090 SCREW PFH
(x24)
8x2 1/2"
H100391
SCREW PFH BLK
(x24)
8x2
H100111 SCREW PFH
(x88) 8x2
H100089 SCREW PFH
(x75) 8x1 3/4
H100200
SCREW PFH BLK
(x8)
8x1 1/2
H100086
SCREW PFH
(x280)
8x1 1/2
H100087 SCREW PFH
(x184) 8x1 1/4
H100088 SCREW PFH
(x30)
8x1 1/8
H100385 SCREW PFH
(x24)
BLK
8x1
Hardware Components
H100202
(x4)
H101167 WASHER FLAT
(x16) BLK
11x25
H101166 WASHER
(x16)
LOCK INT BLK
10x18
H100473 WASHER
(x20) LOCK INT BLK
8x15
H100477 WASHER
(x4)
SPLIT BLK
5/16
11
H100481
(x4)
H101121 BOLT PTH BLK
(x4)
with LOCTITE
1/4x1
SCREW PWH
BLK
8x5/8
H100478 WASHER FLAT
(x8) BLK
8x27
H100199 WASHER
(x7)
LOCK EXT BLK
12x19
H100198 WASHER
(x159)
LOCK EXT BLK
8x19
H100405 WASHER
(x13) LOCK EXT BLK
6x15
BOLT HEX BLK
5/16x1 1/4
H100831 NUT BARREL
(x4)
PTH BLK
1/4x3/4
H101111 BOLT WH BLK
(x20) 1/4x3/4
H101168 T-NUT BLK
(x16) 3/8
H100379 T-NUT BLK
(x188) 5/16
H100398 T-NUT BLK
(x21)
1/4
H100479 NUT LOCK BLK
(x2)
5/16
