Backyard Discovery TIMBER CROSSING Manual page 10

Owner's Manual - Parts Identification
H100480 BOLT WH BLK
(x10) 5/16x4 3/4
H100415 BOLT WH BLK
(x41)
5/16x3 3/4
H100503 BOLT WH BLK
(x15)
5/16x3-1/2
H100484 BOLT WH BLK
(x15) 5/16x3 1/4
H100416
BOLT WH BLK
(x7)
5/16x3
H100195 BOLT WH BLK
(x6)
5/16x2-3/4
H100205 BOLT WH BLK
(x50)
5/16x2-1/4
H100457 BOLT WH BLK
(x6)
5/16x2
H100378 BOLT WH BLK
(x4)
5/16x1 3/4
Hardware Components
H100407
(x15)
H100458 LAG SCREW
(x8) WH BLK
5/16x2
H100197 LAG SCREW
(x20) WH BLK
5/16x2 1/2
H100192 NUT BARREL
(x14) WH BLK
5/16x7/8
H100487
LAG SCREW
(x12)
WH BLK
1/4x2
10
H100396 BOLT WH BLK
(x7) 5/16x1/2
H100468 BOLT WH BLK
(x16)
5/16x1
H100459 BOLT WH BLK
(x6)
5/16x1 1/4
BOLT WH BLK
5/16x1 1/2
H100567 BOLT WH BLK
(x1)
1/4x2 1/4
