PRAIRIE RIDGE
Wooden Swing Set
Model: #55006
• Owner's Manual
• Frequently Asked Questions
• Assembly Instructions
• Warranty Information
Features the
fastening system.
Save this assembly manual for future reference in the event that
you need to order replacement parts.
Made in China

Advertisement

Chapters

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 55006 and is the answer not in the manual?

Questions and answers

Related Manuals for Backyard Discovery 55006

Summary of Contents for Backyard Discovery 55006

  • Page 1 PRAIRIE RIDGE Wooden Swing Set Model: #55006 • Owner's Manual • Frequently Asked Questions • Assembly Instructions • Warranty Information Features the fastening system. Save this assembly manual for future reference in the event that you need to order replacement parts.
  • Page 2 GENERAL SAFETY INSTRUCTIONS PURPOSE This product is intended for outdoor, domestic use only. It is not suitable for commercial or medical use. DANGER FOR CHILDREN  WARNING! No eating while using the product  This product may only be used with adult supervision at all times. ...
  • Page 3  In certain areas during winter, snow buildup and the low temperatures can damage the product. It is recommended to remove snow buildup and to store the product indoor.  We strongly recommend visual inspections every 3 months to insure the integrity of the entire product. Replace any parts as necessary.
  • Page 4 Consumer Information Sheet for Playground Surfacing Materials The US Consumer Product Safety Commission (CPSC) estimates that about 100 000 playground equipment- related injuries resulting from falls to the ground surface are treated annually in US hospital emergency rooms. Injuries involving this hazard pattern tend to be among the most serious of all playground injuries, and have the potential to be fatal, particularly when the injury is to the head.
  • Page 5 10. The end beam is not straight up and down. Why not? This is normal. Backyard Discovery designs playsets this way to ensure the strongest structure possible. The slight angle adds strength and reduces rocking and twisting.
  • Page 6 Tools Required for Installation: (These are the tools that are generally required for assembly of our outdoor products. These tools are not included with the outdoor product purchase.) (Square) (Level 24") (Phillips Screw Driver) (Claw Hammer) (Tape Measure) (Drill Attachments: (3/16"...
  • Page 7 Basic Setup Dimensions Place the set on level ground, not less than 6 ft [2 m] from any structure or obstruction such as a fence, garage, house, overhanging branches, laundry lines, or electrical wires. 20'-3 1/8" [6.2] 10'-9 5/8" [3.3] 6'-0"...
  • Page 8 Parts Identification Wood Components (NOT TO SCALE) E1 - UPRIGHT - W101261 1 3/8"x3 3/8"x81 3/4" (36x86x2076) E2 - UPRIGHT - W103773 1 3/8"x3 3/8"x81 3/4" (36x86x2076) E3 - UPRIGHT - W101256 1 3/8"x3 3/8"x81 3/4" (36x86x2076) E71 - MONKEY BAR RAIL - W102369 1 3/8"x3 3/8"x60 5/8"...
  • Page 9 Parts Identification Wood Components (NOT TO SCALE) H80 - GROUND BOARD - W100990 1"x3 3/8"x87 3/8" (24x86x2218) H81 - MONKEY BAR BRACE - W100993 1"x3 3/8"x53 1/4" (24x86x1352) H82 - MONKEY BAR GROUND BOARD - W100994 1"x3 3/8"x70 3/8" (24x86x1786) J1 - WINDOW LEDGE - W100709 1"x2 3/8"x29 1/2"...
  • Page 10 Parts Identification Wood Components (NOT TO SCALE) K9-3 - WALL BOARD - W101257 3/8"x3 3/8"x42" (11x86x1068) K9-4 - WALL BOARD - W101239 3/8"x3 3/8"x37 3/8" (11x86x950) K9-5 - WALL BOARD - W101259 3/8"x3 3/8"x21 3/8" (11x86x544) L2 - GROUND BOARD - W100684 5/8"x4 3/8"x60 1/8"...
  • Page 11 Parts Identification Wood Components (NOT TO SCALE) M4 - TARP TOP SUPPORT - W100693 5/8"x3 3/8"x60 1/8" (16x86x1528) M5 - FACE BOARD - W101599 5/8"x3 3/8"x43 1/8" (16x86x1094) M6 - LOWER FACE BOARD - W101598 5/8"x3 3/8"x38 5/8" (16x86x982) M7 - WALL BOARD - W100708 5/8"x3 3/8"x35 1/4"...
  • Page 12 Parts Identification Wood Components (NOT TO SCALE) M16 - TARP SUPPORT - W101237 5/8"x3 3/8"x29 1/8" (16x86x740) M17 - PICKET - W100705 5/8"x3 3/8"x27 1/8" (16x86x690) M18 - PICKET - W103761 5/8"x3 3/8"x18 7/8" (16x86x480) M71 - ROCK BOARD - W100022 5/8"x3 3/8"x20 1/4"...
  • Page 13 Parts Identification Hardware (36) Z - LAG SCREW WH 5/16x2 - H100027 (18) B - NUT BARREL WH 5/16x5/8 - H100004 (13) AA - LAG SCREW WH 5/16x2 1/2 - H100028 (45) D - NUT BARREL WH 5/16x7/8 - H100005 (10) F - BOLT WH 5/16x1 - H100008 C - NUT BARREL WH 5/16x1 1/2 - H100006...
  • Page 14 Parts Identification Hardware LC - LAG SCREW WH 1/4x1-1/2 - H100145 BX - WASHER SPLIT 5/16 - H100095 AY - BOLT PTH 1/4x1 - H100061 (11) CG - WASHER LOCK INT 8x15 - H100108 (15) CH - SCREW TAPPING 14x1-1/2 - H100109 (19) CE - WASHER FLAT 9x18 - H100106 (61)
  • Page 15 Parts Identification Hardware (13) CT - SCREW TAPPING 8x1/2 - H100123 CY - SCREW PWH 8x5/8 - H100128 KY - BOLT WH 1/4x1/2" - H100141 (13) CM - BOLT WH 5/16x1/2 - H100115 KS - NUT BARREL WH 1/4x5/8 - H100136 KT - BOLT WH 1/4x1 - H100137 A - BOLT FA 3/8x1 1/2 - H100001 KW - WASHER LOCK EXT 8x15 - H100139...
  • Page 16 Parts Identification Accessories (NOT TO SCALE) DN - GLIDER SEAT DARK GREEN - A100025 DO - CAPTAINS GLIDER ARM YELLOW - A100026 EA - HAND GRIP YELLOW PLASTIC - A100043 EC - METAL RUNG 559 - A100045 ER - CLIMBING ROCK GREEN SMALL - A100060 EJ - L BRACKET 54x67 - A100053 EM - SLIDE BED 8' YELLOW - A100056 EL - SLIDE RAIL 8' GREEN LEFT - A100055...
  • Page 17 Parts Identification A A A A c c c c c c c c e e e e s s s s s s s s o o o o r r r r i i i i e e e e s s s s (NOT TO SCALE) HC - BYD ID TAG (LARGE) 2011 WITH AGES - A100164 TC - SWING BEAM EXTENSION BRACKET-RIGHT - A100326...
  • Page 18 4' Rock Ladder Phase 1 Phase Notes • Assemble slats to rails as shown. • Note oreintation of slats, be sure to arrange as shown. • See drawing below for slat spacing on rails. SCREW PFH 8x1-1/2 • Using slats as a guide, pre-drill top edges of rails with a 1/8"...
  • Page 19 4' Rock Ladder Phase 2 & 3 P h h h h a a a a s s s s e e e e N N N N o o o o t t t t e e e e s s s s •...
  • Page 20 SB74 - SWING BEAM EXTENDED - W102419 2"x5 1/4"x89 1/2" (50x134x2274) GD - L BRACKET 66x66x127 - A100140 TC - SWING BEAM EXTENSION BRACKET-RIGHT - A100326 TB - SWING BEAM EXTENSION BRACKET-LEFT - A100325 4 FT GREEN EXTENDED SWING BEAM WITH GLIDER BOLT WH 5/16x1-3/4 BOLT HEX...
  • Page 21 E77 - ANGLE BRACE - W100991 W71 - SWING BEAM SUPPORT - W102420 1 3/8"x3 3/8"x74 3/8" (36x86x1890) 2"x3 3/8"x49 5/8" (50x86x1260) H79 - END SUPPORT - W100992 H80 - GROUND BOARD - W100990 1"x3 1/2"x42" (24x86x1072) 1"x3 3/8"x87 3/8" (24x86x2218) STEP 2 ATTACH H80 GROUND BOARD TO (2) E77 ANGLED SUPPORT BOARDS USING (2) 2"...
  • Page 22 STEP 3 INSERT W71 BOARD INTO TB AND TC BRACKET OPENING AND SECURE USING (2) 1-3/4" BOLTS AND 7/8" BARREL NUTS, AS SHOWN. BOLT WH INSERT (2) 2-1/2" BOLTS, LOCK WASHERS AND 1-1/2" BARREL NUTS INTO THE EDGE OF 5/16x1-3/4 BOLT WH W71 BOARD, AS SHOWN.
  • Page 23 EY - TUBING CAP GLIDER SUPPORT - A100067 EX - GLIDER BUSHING BYD GREEN - A100066 EW - GLIDER SUPPORT BYD GREEN - A100065 STEP 4 ATTACH (2) EW GLIDER SUPPORT BARS TO SB74 SWING BEAM USING (2) 5-3/4" BOLTS, FLAT WASHERS AND 5/16"...
  • Page 24 STEP 5 INSERT (4) SWING HANGER QUICK LINK INTO SB74 SWING BEAM USING (4) SAFETY NUT LOCK 5/16 WASHERS, FLAT WASHERS AND 5/16" LOCK NUTS, AS SHOWN. WASHER FLAT 8x27 SB74 WASHER SAFETY 17x30 SWING HANGER QUICK LINK...
  • Page 25 8 FOOT SLIDE ASSEMBLY PHASE 1 STEP 1 PLACE SLIDE BRACE CENTERED ON THE BOTTOM 1/4" FROM THE EDGE. TRANSFER HOLES ON THE BOARD THROUGH THE SLIDE BED AS SHOWN BELOW. USE A 3/8" DRILL BIT. ATTACH SLIDE BRACE TO SLIDE USING HARDWARE SHOWN. DESCRIPTION SLIDE BRACE BOLT WH 5/16x1/2...
  • Page 26 8 FOOT SLIDE ASSEMBLY PHASE 2 STEP 2 PLACE 1 SLIDE RAIL ON A FLAT SURFACE AND BEGIN INSERTING SLIDE BED AT THE BOTTOM OF THE SLIDE RAIL (FIG. 1). PUT SLIDE SUPPORT BOTTOM INTO THE SUPPORT POCKET AT THE BOTTOM OF THE RAIL AND HAVE A HELPER BEND THE SLIDE BED TOWARDS THE TOP OF THE SLIDE AND INSERT THE BED INTO THE SLIDE CAVITY.
  • Page 27 E71 - MONKEY BAR RAIL - W102369 EJ - L BRACKET 54x67 - A100053 1 3/8"x3 3/8"x60 5/8" (36x86x1539) QZ - TRIANGLE PLATE 100 5 HOLE - A100294 MONKEY BAR ASSEMBLY STEP 1 BOLT WH 5/16x1 YOU WILL BUILD A LEFT AND RIGHT TOP RAIL IN THIS STEP. BOLT WH 5/16x1-1/2 AFTER BUILDING LEFT ASSEMBLY AS SHOWN, REPEAT STEPS...
  • Page 28 E78 - MONKEY BAR UPRIGHT - W102370 1 3/8"x3 3/8"x74 3/4" (36x86x1900) MONKEY BAR ASSEMBLY STEP 2 ASSEMBLE WITH HARDWARE AS SHOWN. BOLT WH REPEAT PROCESS FOR OTHER SIDE OF MONKEY BAR ASSEMBLY. 5/16x1-1/2 T-NUT 5/16...
  • Page 29 EC - METAL RUNG 559 - A100045 MONKEY BAR ASSEMBLY STEP 3 ASSEMBLE AS SHOWN INTO PRE-DRILLED HOLES. SCREW (12) TAPPING 14x1-1/2...
  • Page 30 H81 - MONKEY BAR BRACE - W100993 1"x3 3/8"x53 1/4" (24x86x1352) H82 - MONKEY BAR GROUND BOARD - W100994 1"x3 3/8"x70 3/8" (24x86x1786) MONKEY BAR ASSEMBLY LAG SCREW WH 5/16x2 BOLT HEX 5/16x2-3/4 WASHER WASHER LOCK EXT LOCK INT 8x19 8x15 WASHER WASHER...
  • Page 31 EA - HAND GRIP YELLOW PLASTIC - A100043 MONKEY BAR ASSEMBLY LAG SCREW WH 1/4x1-1/2 WASHER LOCK EXT 6x15 STEP 5 ASSEMBLE WITH HARDWARE AS SHOWN.
  • Page 32 M5 - FACE BOARD - W101599 E2 - UPRIGHT - W103773 5/8"x3 3/8"x43 1/8" (16x86x1094) 1 3/8"x3 3/8"x81 3/4" (36x86x2076) STEP 1 ATTACH M5 BOARDS TO E2 BOARDS USING HARDWARE AS SHOWN THROUGH PRE DRILLED HOLES. NOTE THE ORIENTATION OF THE HOLES WITH THE E2 BOARDS. SCREW PFH 8x1 1/2 SCREW PFH 8x1 1/2...
  • Page 33 E3 - UPRIGHT - W101256 M6 - LOWER FACE BOARD - W101598 1 3/8"x3 3/8"x81 3/4" (36x86x2076) 5/8"x3 3/8"x38 5/8" (16x86x982) E1 - UPRIGHT - W101261 L5 - GROUND BOARD - W100686 1 3/8"x3 3/8"x81 3/4" (36x86x2076) 5/8"x4 3/8"x30" (16x112x762) STEP 2 ATTACH THE M6 BOARDS AND THE L5 BOARD TO THE E3 AND E1 BOARDS USING HARDWARE AS SHOWN THROUGH PRE DRILLED HOLES.

  • Page 34: Table Of Contents

    L2 - GROUND BOARD - W100684 5/8"x4 3/8"x60 1/8" (16x112x1528) STEP 3 NUT BARREL ATTACH THE L2 BOARDS TO THE E1, E3 AND E2 BOARDS USING WH 5/16x7/8 HARDWARE AS SHOWN THROUGH PRE DRILLED HOLES. WASHER LOCK EXT 12x19 BOLT WH 5/16x1 1/2 WASHER LOCK EXT...
  • Page 35 M9 - ANGLE BRACE - W100696 M10 - SAFETY BOARD - W100701 L3 - GROUND BOARD - W101602 5/8"x3 3/8"x35 5/8" (16x86x904) 5/8"x3 3/8"x33 7/8" (16x86x860) 5/8"x4 3/8"x46 7/8" (16x112x1191) STEP 4 ATTACH M10 AND L3 BOARDS TO THE M5 BOARDS USING HARDWARE AS SHOWN THROUGH PRE DRILLED HOLES.
  • Page 36 M13 - FLOOR RAIL - W103774 K4 - FLOOR RAIL - W103700 5/8"x3 3/8"x60 1/8" (16x86x1528) 5/8"x5 1/4"x60 1/8" (16x134x1528) STEP 5 ATTACH M13 BOARD TO THE E1 BOARD AND THE E2 BOARD USING HARDWARE SHOWN THROUGH PRE DRILLED HOLES. NOTE THE ORIENTATION OF HOLES THAT BOLT WH WILL BE USED LATER IN THE M13 BOARD.

  • Page 37: Washer Lock Ext 8X19 (8 Plcs)

    M14 - FLOOR SUPPORT BOARD - W103944 K5 - FLOOR RAIL - W103768 5/8"x3 3/8"x30" (16x86x762) 5/8"x5 1/4"x30" (16x134x762) STEP 6 ATTACH K5 BOARD TO E2 BOARDS AND ATTACH M14 BOARD TO E1 AND E3 BOARDS USING HARDWARE AS SHOWN THROUGH PRE DRILLED HOLES . LAG SCREW WH 5/16x2 WASHER LOCK EXT 8x19...

  • Page 38: (8 Plcs)

    SP1 - FLOOR SUPPORT CLEAT - W100711 F71 - STANDARD ANGLE BRACE - W100689 1"x1"x53 3/8" (24x24x1356) 1 3/8"x2 3/8"x13" (36x60x330) J2 - END FLOOR CLEAT - W100710 1"x2 3/8"x3 3/8" (24x60x86) STEP 7 FIRST ATTACH A F71 BRACE TO A M13 BOARD AND A F71 BRACE TO A K4 NUT BARREL BOARD USING HARDWARE AS SHOWN THROUGH PRE DRILLED HOLE.

  • Page 39: Washer (8) Lock Ext

    J3 - FLOOR JOIST - W100984 F71 - STANDARD ANGLE BRACE - W100689 1"x2 3/8"x60 1/8" (24x60x1528) 1 3/8"x2 3/8"x13" (36x60x330) STEP 8 ATTACH F71 BRACES TO K5 AND M14 BOARDS THROUGH PRE DRILLED HOLES WITH NUT BARREL HARDWARE AS SHOWN WH 5/16x7/8 LAG SCREW PRE DRILL E1, E3, AND E2 BRACES AND FASTEN F71 BOARDS TO THEM WITH...
  • Page 40 L9 - END FLOOR BOARD - W102863 5/8"x4 3/8"x29 7/8" (16x112x760) STEP 9 PLACE L9 BOARDS ON THE J3 FLOOR JOIST AND J2 SUPPORT BOARDS. L9 BOARD WILL SIT UP AGAINST THE E2 BOARDS AND THE E3 AND E1 BOARD AS SHOWN.
  • Page 41 (3) FP1 - FLOOR PANEL - W102861 STEP 10 ATTACH FP1 FLOOR PANELS TO SP1 BOARDS AND J3 FLOOR JOIST USING HARDWARE AS SHOWN THROUGH PRE DRILLED HOLES. SCREW PFH (45) 8x1 1/2 SCREW PFH 8x1 1/2 (45 PLCS)
  • Page 42 M11 - UPPER FACE BOARD - W102866 M12 - MONKEY BAR ARCH BOARD - W103775 5/8"x3 3/8"x26 5/8" (16x86x676) 5/8"x3 3/8"x30" (16x86x762) STEP 11 ATTACH 1/4" T-NUTS TO M11 BOARDS AS SHOWN. ATTACH M11 BOARDS TO E1 BOARD AND E3 BOARD WITH HARDWARE AS SHOWN THROUGH PRE DRILLED HOLES.
  • Page 43 L6 - ARCHED RAIL - W100694 L7 - ARCHED SCULPTURED RAIL - W100695 5/8"x4 3/8"x60 1/8" (16x112x1528) 5/8"x4 3/8"x60 1/8" (16x112x1528) STEP 12 ATTACH L6 BOARD AS SHOWN TO E1 AND E2 BOARDS THROUGH PRE DRILLED HOLES USING HARDWARE AS SHOWN. NUT BARREL WH 5/16x7/8 ATTACH L7 BOARD AS SHOWN TO E3 AND E2 BOARDS THROUGH PRE DRILLED...
  • Page 44 K1 - ROOF SWING BEAM SUPPORT - W100682 K2 - ROOF SUPPORT - W100683 5/8"x5 1/4"x51 5/8" (16x134x1310) 5/8"x5 1/4"x51 5/8" (16x134x1310) STEP 13 ATTACH 5/16 T NUTS TO K1 BOARD AS SHOWN AND ATTACH TO E2 BOARDS THROUGH PRE DRILLED HOLES WITH HARDWARE AS SHOWN. ATTACH K2 BOARD TO E1, AND E3 BOARDS WITH HARDWARE AS SHOWN THROUGH PRE DRILLED HOLES.
  • Page 45 M1 - PICKET RAIL - W103760 M18 - PICKET - W103761 5/8"x3 3/8"x30" (16x86x762) 5/8"x3 3/8"x18 7/8" (16x86x480) STEP 14 ATTACH M1 BOARD TO E2 BOARDS AS SHOWN. ATTACH M18 PICKETS TO M1 BOARD AND K5 BOARD USING SPACING AS SHOWN SCREW PFH (16) 8x1 1/8...
  • Page 46 M8 - WALL RAIL - W100700 M7 - WALL BOARD - W100708 5/8"x3 3/8"x35 7/8" (16x86x910) 5/8"x3 3/8"x35 1/4" (16x86x895) STEP 15 ATTACH M7 BOARD TO L6 BOARD AND M13 BOARD THROUGH PRE DRILLED NUT BARREL HOLES USING HARDWARE AS SHOWN. WH 5/16x5/8 ATTACH M8 BOARD TO M7 BOARD AND E1 BOARD USING HARDWARE AS SCREW PFH...
  • Page 47 M17 - PICKET - W100705 5/8"x3 3/8"x27 1/8" (16x86x690) STEP 16 ATTACH M17 PICKETS TO L6 AND M8 BOARDS USING SPACING AND HARDWARE AS SHOWN THROUGH PRE DRILLED HOLES. SCREW PFH 8x1 1/8 (16 PLCS) SCREW PFH (16) 8x1 1/8 3 1/8"...
  • Page 48 K9-2 - WALL BOARD - W100712 3/8"x3 3/8"x30 1/4" (11x86x768) K9-1 - WALL BOARD - W100713 3/8"x3 3/8"x15 3/4" (11x86x400) J1 - WINDOW LEDGE - W100709 1"x2 3/8"x29 1/2" (24x60x750) STEP 17 PLACE (2) K9-2 BOARDS ON FLOOR AGAINST L7 AND K4 BOARDS, AND AGAINST E3 BOARD LIP OF K9-2 TOUCHING E3 BOARD AND ATTACH WITH HARDWARE AS SHOWN THROUGH PRE DRILLED HOLES.
  • Page 49 M3 - TARP SUPPORT - W100692 5/8"x3 3/8"x60 1/8" (16x86x1528) STEP 18 ATTACH M3 BOARDS TO K1 AND K2 BOARDS THROUGH PRE DRILLED HOLES USING HARDWARE AS SHOWN. SCREW PFH 8x2 SCREW PFH (8PLCS)

  • Page 50: Bolt Wh 5/16X1 (2 Plcs)

    M16 - TARP SUPPORT - W101237 M4 - TARP TOP SUPPORT - W100693 5/8"x3 3/8"x29 1/8" (16x86x740) 5/8"x3 3/8"x60 1/8" (16x86x1528) STEP 19 ATTACH M16 BOARDS AS SHOWN TO K1 AND K2 BOARDS. BOLT WH 5/16x1 ATTACH M4 BOARD FLUSH TO M16 BOARDS AS SHOWN.
  • Page 51 HY - TARP 1522x2119 - A100062 1/32"x59 7/8"x83 3/8" (.4x1522x2119) STEP 20 CENTER HY TARP OVER M4 TARP TOP SUPPORT AND ATTACH USING (4) 1/2" TAPPING SCREWS, AS SHOWN. NEXT, DRAPE HY TARP EVENLY OVER (2) M3 TARP SUPPORTS AND WRAP UNDERNEATH AND UP THE BACK SIDE OF M3 SUPPORT APPROXIMATELY 1-13/16"...
  • Page 52 K9-3 - WALL BOARD - W101257 L8 - SCULPTURED RAIL - W101240 3/8"x3 3/8"x42" (11x86x1068) 5/8"x4 3/8"x35 1/2" (16x112x902) K9-5 - WALL BOARD - W101259 K9-4 - WALL BOARD - W101239 3/8"x3 3/8"x21 3/8" (11x86x544) 3/8"x3 3/8"x37 3/8" (11x86x950) STEP 21 ATTACH L8 BOARD TO E3 BOARD FLUSH WITH THE UNDERSIDE OF K4 BOARD USING HARDWARE AS SHOWN FIG.
  • Page 53 H3 - SERVING BOARD SUPPORT - W101606 H1 - SERVING SHELF SUPPORT - W101604 K3 - SERVING BOARD - W101605 1"x3 3/8"x3 3/8" (24x86x86) 1"x3 3/8"x30 3/4" (24x86x780) 5/8"x5 1/4"x28 3/4" (16x134x729) STEP 22 ATTACH H3 SHELF SUPPORTS TO K3 AND H1 BOARDS USING HARDWARE AS SHOWN THROUGH PRE DRILLED HOLES.
  • Page 54 EA - HAND GRIP YELLOW PLASTIC - A100043 STEP 24 ATTACH EA HANDLE TO E2 BOARD USING HARDWARE AS SHOWN (FIG. 1). INSERT 1/4" T-NUTS INTO M7 BOARD AND ATTACH EA HANDLE AS SHOWN (FIG. 2). BOLT PTH 1/4x1 ATTACH 2 EA HANDLES TO M11 BOARDS USING PREVIOUSLY INSERTED T-NUTS. SCREW TAPPING 14x1-1/2...

  • Page 55: Washer Lock Ext 12X19 (2 Plcs)

    M2 - BENCH SEAT - W104044 H4 - BENCH SEAT SUPPORT - W104040 5/8"x3 3/8"x27 3/8" (16x86x694) 1"x3 3/8"x6 1/2" (24x86x166) EJ - L BRACKET 54x67 - A100053 H5 - BENCH UPRIGHT - W104041 H6 - BENCH GROUND BOARD - W104042 1"x3 3/8"x11 3/4"...

  • Page 56: Washer Lock Ext

    (1) - BENCH ASSEMBLY STEP 26 USING BENCH ASSEMBLY BRACKETS AS A TEMPLATE, DRILL TWO 3/8" THRU HOLES AND ATTACH EJ BRACKET TO L2 GROUND BOARD USING (2) 1/2" BOLTS, LOCK BOLT WH WASHERS AND 5/8" BARREL NUTS, AS SHOWN. 5/16x1/2 WASHER LOCK EXT...
  • Page 57 (1) - SLIDE ASSEMBLY STEP 27 CENTER THE WAVE SLIDE ASSEMBLY IN OPENING, AS SHOWN. BOLT WH 5/16x1/2 USING A 3/8" DRILL BIT, DRILL THREE THROUGH HOLES INTO THE SLIDE BED AND DECK BOARDS, AS SHOWN BELOW. ATTACH THE SLIDE ASSEMBLY TO THE DECK USING (3) 1/2" BOLTS, LOCK WASHERS AND 5/8"...

  • Page 58: Washer Lock Ext 8X19 (2 Plcs)

    (1) - ROCK LADDER ASSEMBLY STEP 28 CENTER LADDER ON 'M13' BOARD AND PILOT DRILL 3/16" HOLES FOR LADDER ATTACHMENT. ATTACH THE ROCK LADDER ASSEMBLY TO M13 FLOOR RAIL SUPPORT USING (2) 2-1/2" LAG SCREWS AND LOCK WASHERS, AS SHOWN. LAG SCREW WH 5/16x2 1/2 WASHER...
  • Page 59 (1) - SWING BEAM ASSEMBLY HC - BYD ID TAG (LARGE) 2011 WITH AGES - A100164 STEP 29 ATTACH SWING BEAM ASSEMBLY TO K1 ROOF SWING BEAM SUPPORT USING (4) 1" BOLTS, SPLIT WASHERS AND FLAT WASHERS, AS SHOWN BELOW. SCREW PWH 8x5/8 ATTACH HC I.D.
  • Page 60 (1) - MONKEY BAR ASSEMBLY STEP 30 ATTACH MONKEY BAR ASSEMBLY TO M12 ARCH BOARD USING HARDWARE AS SHOWN. BOLT WH 5/16x1/2 WASHER LOCK EXT 12x19 NUT BARREL WH 5/16x5/8 NUT BARREL WH 5/16x5/8 (2 PLCS) WASHER LOCK EXT 12x19 (2 PLCS) BOLT WH 5/16x1/2 (2 PLCS)
  • Page 61 EZ - CHAIN GREEN 51.25" - A100068 FB - SWING SEAT YELLOW - A100070 JD - CHAIN GREEN 45" - A100092 DO - CAPTAINS GLIDER ARM YELLOW - A100026 DN - GLIDER SEAT DARK GREEN - A100025 STEP 31 ATTACH FB SWING SEAT TO (2) EZ CHAINS USING (2) FA QUICK LINKS, AS SHOWN. REPEAT PROCESS TO ASSEMBLE SECOND SWING ASSEMBLY.
  • Page 62 SR - "B" REVISION TAG - A100315 KC - METAL GROUND STAKE BROWN - A100178 Anchoring Instructions BOLT WH STAKE A STAKE A 1/4x1/2" NOTE: BOLT WH 1/4x1 FAILURE TO USE GROUND STAKES CAN VOID WARRANTY & CAUSE INJURY! WASHER LOCK EXT 8x15 STAKE A...
  • Page 63 WARRANTY AUSTRALIAN CONSUMER LAW Many of our products come with a guarantee or warranty from the manufacturer. In addition, they come with guarantees that cannot be excluded under the Australian Consumer law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
