Section 3: Compatible Panels

Compatible Potter fire panels must have Version 10.1 (or higher)
• IPA-4000
• IPA-4000V
• IPA-100
• IPA-60
• AFC-1000
• AFC-1000V
• AFC-100
• AFC-50
• ARC-100
• PFC-4064
DACT Connected Panels:
• Any UL Listed alarm panel that supports one of the supported formats.

Section 4: Specifications

Specifications
Cellular Service
Dimensions
Material/Color
Primary Power
Standby Current
Transmit Current
Dact Panels
Ethernet Panels
(UD-2000 NOT REQ.)
(Contact ID)
INTELLICOM • 5403797 • REV A • 8/23
5G-LTE - Verizon or AT&T
7.5" H x11.5" W x 3.5" D
Steel/Red
12VAC or 12/24VDC
64mA @ 24VDC
140MA @ 24VDC
All panels w/ dialer
IPA-4000(V), IPA-100, IPA-
60, AFC-1000(V), AFC-100,
AFC-50, ARC-100, PFC-4064
