RJ-45 Jack Pin Assignments
Jack
Connects To
Digital Dialer input/
Black
output of host alarm
panel (DACT)
Router, Switch, or other
Silver
LAN port
DC Terminal Strip Pin Assignments
Terminal
Definition
Strip Pin
1 GND
Power Input
2 DC
Main Terminal Strip Pin Assignments
Terminal Strip Pin
Definition
Supervisory Relay Trip output
1 STC2
for programmable trouble
2 STC2
conditions. Normally Open
Supervisory Relay Trip output
3 STC1
for programmable trouble
4STC1
conditions. Normally Open
5 GND
Trip Ground and Trip Input
6 IN
AC Terminal Strip Pin Assignments
Terminal Strip Pin Definition
1 AC
AC Power Input
2 AC
INTELLICOM • 5403797 • REV A • 8/23
Pin Assignment
1 = Brown R1
2 = Blue
4 = Green R (RING)
5 = Red T (TIP)
7 = ORANGE
8 = GRAY T1
Per CAT-5 or higher
standard, Crossover
cables and PoE not
supported
Connects To
Function
12- or 24- VDC
Provides power to
Regulated Source
the unit
Connects To
24-hour trip zone
input on alarm panel
24-hour trip zone
input on alarm panel
External trip relay
Connects To
Provided AC
adapter (120VAC,
160mA)
Function
Connects alarm panel
to communicator for
transmitting alrm signals
to TCC.
Connects communicator
to premises LAN for
transmitting alarm
signals to TCC via
internet.
LED Reference
Power LED 8 on
for valid power
Function
Enables transmission of programmed
supervisorory trouble code (see
diagram or installation section)
Enables transmission of programmed
supervisorory trouble code (see
diagram or installation section)
Allows an external relay to trigger an
alarm signal
Function
Provides primary power to
communicator and battery-
charging circuit.
A-30
Status LED Reference
If PPF is ENABLED STC LED 2
will flash 7 times when alarm panel
is not detected.
LED 6 stays illuminated for verified
connection. Otherwise STC LED 2
will flash 3 times and flash pattern
on LED 6 will indicate reason.
Note
Consumption rates vary based
on input voltage used
Status LED
Reference
STC LED 2
STC LED 2
LED 7
LED Reference
Power LED 8 ON when AC is
normal, OFF and STC LED 2
flashes 1 time when AC is low.
