IntelliCom. This feature is not required in UL 864. Settings include:
• Enable End-to-End Acknowledgement: On/Off
• Trip Input Settings: When the input is tripped, a supervisory message is sent to the Central Station. This
allows an external relay, separate from the alarm panel, to be connected to IntelliCom in order to provide
independent sensor input for other functions, such as tamper detection. The message that is sent to the
Central Station is configurable. IntelliCom will automatically be configured with a unit template that
allows configuration of the trip input feature, including the message that is sent to the Central Station.
If IntelliCom is configured to report restorals, the contact closure will also be reported. The trip input is
normally wired such that there is a 2.2k ohm resistor in parallel with the external relay, so that a tamper
condition (e.g., a cut wire) can be detected.
• The swinger function is designed to reduce the incidence of excessive messaging and alarms due to faulty
equipment or installation. If enabled, the swinger function will discontinue sending trip input messages to
the PCC once 10 trip events are detected within a 10-minute period. IntelliCom will resume sending trip
input messages to the PCC after a 10-minute period without trip events.
• Enable Trip Input Settings: On/Off
• Swinger Settings: On/Off
• All Events Reporting: On/Off – Configure message.
• All Events Restoral: On/Off - Configure message.
16. Select Next Step
17. Select Billing Plan
• Sole Path or Dual Path
18. Select Next Step
19. Check your settings.
20. Select Register Subscriber
• You should get a pop-up with a green check that says "Your subscriber has been registered. The subscriber
number is XXXXXXX."
21. Select Ok
22. Plug in the ethernet cable between the fire panel and IntelliCom Gateway
23. Plug in your IntelliCom Gateway to the FACP DC or external AC (or cycle power on the IntelliCom Gateway if it
was already powered). This will initiate the program to be downloaded to the IntelliCom Gateway.
24. Wait for any IPDACT or other related troubles to go away. The panel should go to an All Systems Normal state.
25. Create an event on the fire alarm control panel to activate the IntelliCom Gateway.

IntelliView Registration of IntelliCom Gateway

To utilize the IntelliView services with your IntelliCom device, it is necessary to register your IntelliCom.
Please follow the provided step-by-step instructions:
1. Visit www.potterintelliview.com.
2. Log in using the credentials you previously created.
3. In the left-hand side panel, select "Settings" and then choose "Account Settings."
4. Under "Potter IntelliCom Username," enter the username you created on PotterIntelliCom.com.
5. Click on "Register device" (located at the top of the screen, marked with a "+" symbol).
6. Select "IntelliCom Advanced Gateway" from the drop-down menu under "Device Type."
7. Choose to add the gateway to an existing location or create a new one, as per your preference.

Post-Installation Remote Programming

To continue to meet compliance requirements, once a unit is installed it cannot be remotely reprogrammed or
receive updated firmware from Potter Technical Support without manual onsite intervention. To change the device
settings or accept updated firmware, follow these steps:
1. Locate and press the RSSI button on IntelliCom, holding it for at least 5-7 seconds.
2. LED 5 will flash, indicating that a message has been sent to initiate a Maintenance Window.
3. The maintenance window will last for 10 minutes after receipt of the device message.
4. Log into the PotterIntellicom.com dealer portal and make the necessary configuration changes to the device, within
the observed maintenance window (10 minutes).
5. No device configuration changes can be made outside of the maintenance window.
