Connecting Ethernet and Serial Cables for Array Management

007-4798-001
There are two methods of managing the storage system: in-band management and out-of-band
management. In-band management requires that only the Fibre Channel host interface is present
and functional. Out-of-band management requires that Ethernet or serial connections are cabled
to each controller.
Note: For more information on storage management, see the SGI TPSSM Administration Guide
(007-4306-00x), the SGI TPSSM Software Concepts Guide (007-4305-00x), and the SGI Storage
Area Network Installation Instructions (108-0252-00x).
To connect Ethernet or serial (RS-232) interface cables to the controller enclosure for direct
management of the storage array, follow the steps in this section. Optionally, you can use the
Ethernet or serial connectors for diagnostic procedures.
Warning:
Electrostatic discharge can damage sensitive components. Use appropriate
antistatic precautions before handling any components.
