Connecting Ethernet and Serial Cables for Array Management

007-4644-001
There are two methods of managing the storage system: in-band management and
out-of-band management. In-band management requires that only the Fibre Channel
host interface is present and functional. Out-of-band management requires that Ethernet
or serial connections are cabled to each controller.
Note: For more information on storage management, see the SGI TP9400 and SGI TP9500
RAID Administration Guide (007-4306-00x), the SGI TP9400 and SGI TP9500 Software
Concepts Guide (007-4305-00x), and the SGI Storage Area Network Installation Instructions
(108-0252-00x).
To connect Ethernet or serial (RS-232) interface cables to the controller enclosure for
direct management of the storage array, follow the steps in this section. Optionally, you
can use the Ethernet or serial connectors for diagnostic procedures.
Warning:
Electrostatic discharge can damage sensitive components. Use
appropriate antistatic precautions before handling any components.
Connecting the System to the Hosts
73
