007-4798-001
Controller
Lever
Figure 4-6
Removing and Installing a RAID Controller Module
11. Check the power and fault indicators on the new controller as follows (see Figure 4-5):
• If the power indicator is off, the controller module may not have been inserted correctly.
Remove the module and reinsert it.
• If the fault indicator is on, the power indicator stays off, or any other fault indicator is
on, use TPSSM to determine the problem.
12. See TPSSM for instructions on bringing the RAID controller online.
Replacing a Failed RAID Controller Module
57
