3: Operating Storage Enclosures
Component Indicator Light
RAID controller Host 1 link
module Host 2 link
Host 1 speed
Host 2 speed
Battery
charging/charged
Cache active
Fault
Expansion loop
Expansion loop bypass Amber
Environmental Environmental card
status module fault indicator
Environmental card
power indicator
In, out bypass
indicators
Overtemp indicator
ID conflict indicator
40
Table 3-2 describes the rear indicators on the expansion enclosure and RAID controller.
Note: The normal operating state of all indicators on the rear panel is green. If an amber indicator
is on, or a green indicator is off, use TPSSM to determine the nature of the fault and the recovery
procedure.
Table 3-2
Storage Enclosure Rear Indicator Lights
Color Normal Operation
Green On
Green On: 2 Gbit/s data rate
from host
Off: 1 Gbit/s data rate
from host
Green On: battery charged
Flashing: battery
charging
Green On
Amber Off
Green On
Off
Amber Off
Green On, steady
Amber Off
On, steady
d Amber Off
Amber Off
Problem
Indicator Condition Indicated
Off No connection to host
None
Off Battery failure
Off Cache failure
On General failure
Off
On
On, Failure of environmental card canister.
steady
Off No power to drive enclosure; no power to storage
array; overtemp condition; power supply failure.
On, SFP failure; cable failure; controller enclosure
b steady c minihub failure.
On, Overtemp condition; fan failure.
steady
On, Enclosure number is set incorrectly; enclosure
steady number is in use by another subsystem on the
loop.
a
