4.

Replacing a Failed Disk Drive

007-4798-001
Chapter 4

Replacing Enclosure Components

This chapter describes how to replace each component in the enclosure in the following sections:
• "Replacing a Failed Disk Drive" on page 47
• "Replacing a Failed Fan" on page 50
• "Replacing a Failed Power Supply Module" on page 52
• "Replacing a Failed SFP Transceiver" on page 54
• "Replacing a Failed RAID Controller Module" on page 56
• "Replacing a Failed Environmental Status Module" on page 58
• "Upgrading Drives" on page 61
• "Adding Expansion Enclosures" on page 65
When the storage management software (TPSSM) instructs you to replace a failed drive module,
read "Disk Drives" on page 18, and then follow the steps in this section.
Warning:
Electrostatic discharge can damage sensitive components. Use a grounded
wrist strap or other antistatic precautions before handling enclosure components.
47
