4: Replacing Enclosure Components
!
62
7. Review all documentation shipped with the new drive module for updated replacement
procedures and other information.
Caution: If the temperature of the shipping or storage environment differs significantly from
the temperature of the environment in which the drive module will be installed, acclimate the
drive module before you install it.
8. Slide the new drive module fully into the slot.
9. Lower (close) the lever.
10. Check to be sure that the drive activity indicators are on and that the fault indicators above
the new drive module are off.
Note: The fault indicator may flash intermittently while the drive spins up.
• If the activity indicator is off, the drive module may not be installed correctly. Remove
the drive module, wait 30 seconds, and then reinstall it.
• If the fault indicator stays on, or the activity indicator stays off, the new drive may be
bad. Use TPSSM to determine the problem.
11. Configure the new drive using TPSSM.
If you need to install more than one drive module, repeat the steps in this section.
