4: Replacing Enclosure Components
64
5. Turn off both power switches on the rear of the enclosure.
6. Wearing antistatic protection, lift (open) the lever of a drive module and pull out the drive
module (see Figure 4-1 on page 48).
7. Repeat step 6 for all of the drive modules in the enclosure.
8. Unpack a new drive. Save the packing material and documentation in case you need to return
the drive.
9. Slide the new drive module fully into a slot.
10. Lower (close) the lever.
11. Repeat steps 8 through 10 until you have installed all the new drives.
12. Turn on both power switches on the enclosure.
13. Check to be sure that the drive activity indicators are on and that the fault indicators above
the new drive modules are off.
Note: The fault indicator may flash intermittently while the drive spins up.
• If the activity indicator is off, the drive module may not be installed correctly. Remove
the drive module, wait 30 seconds, and then reinstall it.
• If the fault indicator stays on, or the activity indicator stays off, the new drive may be
bad. Use TPSSM to determine the problem.
14. Use TPSSM to configure the new drives. See your software documentation for detailed
instructions.
15. Restore the data from backup to all the drives.
