Figure 5-5 Drive Loop Cabling For Systems With Eight Enclosures - Silicon Graphics InfiniteStorage S330 RAID User Manual

5: Cabling
74
Controller A
drive channel 1
Drive loop A
1Gb 2Gb
Conflict
X10 X1
Tray Number
1Gb 2Gb
Conflict
X10 X1
Tray Number
1Gb 2Gb
Conflict
X10 X1
Tray Number
1Gb 2Gb
Conflict
X10 X1
Tray Number
2Gb
1Gb
Conflict
X10 X1
Tray Number
2Gb
1Gb
Conflict
X10 X1
Tray Number
1Gb 2Gb
Conflict
X10 X1
Tray Number
1Gb 2Gb
Conflict
X10 X1
Tray Number
Figure 5-5
Drive Loop Cabling for Systems with Eight Enclosures
Controller B
drive channel 2
Drive loop B
Controller
enclosure ID 00
Disk drive
enclosure ID 01
Disk drive
enclosure ID 02
Disk drive
enclosure ID 03
Disk drive
enclosure ID 04
Disk drive
enclosure ID 05
Disk drive
enclosure ID 06
Disk drive
enclosure ID 07
007-4798-001
