DSS-5000 HD
10. A listing of detected Configured WiFi networks is dis-
played.
To select a network: For initial setup, no networks will be
displayed here yet.
To add a network: Tap the plus (+) sign, then select from
one of the displayed detected networks.
To manually add a network, tap the plus (+) sign again.
Follow the on-screen instructions to select the Network
SSID, Security, and IP Settings. Tap Next when finished.
Use the on screen keypad to manually enter the Network
SSID, security type, and IP settings. If necessary, enter the
WiFi network password. Tap Next when finished.
A confirmation screen is displayed when the analyzer has
successfully connected to the WiFi network.
To delete a network: Tap a displayed network to select it.
3
Tap trash can icon ( ) to delete it.
11. The BMIS (Battery Management Information System) Account
screen is displayed. Enter the Midtronics-supplied user-
name and password.
Tap Next to connect to the BMIS database.
NOTE: BMIS is an additional add-on data man-
agement subscription service.
12. The Email Address Book screen (Admin Only) is displayed.
To add an email address: Tap the plus (+) sign, then use
the displayed keyboard to add the address.
To edit an email address: Tap the pencil
the displayed keyboard to edit the address.
To delete an email address: Tap a displayed email address
to select it. Tap trash can icon (
To use the Default Email Server Settings: Tap the gear
icon to use the default.
13. The Shop Information screen (Admin Only) is displayed
Use the on screen keypad to enter the store name,
address, and phone number. Tap Next to continue.
Store Name
Street Address
Street Address 2
City
State
Zipcode
Phone #
icon, then use
3
) to delete it.
Midtronics
7000 Monroe
Willowbrook
IL
60527
1-630-323-2800
14. The login screen is displayed.
15. Tap a user name to access the Main Menu.

Main Menu

 
Menu Bar
Log out current user
Log Out
Bluetooth
connectivity status
WiFi signal strength
 
Main Menu Selection Area

Additional Screens

Dots at the bottom or side of a menu or results screen indicate
additional screens are available. Swipe horizontally or vertically
across the Controller screen to view all of the results.
Screen 1

Screen 2

Screen 3

Swipe
Horizontally
Chapter 1: Introduction
Controller internal
93%
battery level
Controller internal
battery status

Screen 1


Screen 2

Swipe
Vertically
