DSS-5000 HD
Use History to access the tool usage history,
a vehicle history based on Vehicle ID, and
user histories. The search function can also be
History
used find test records for specific vehicles and
technicians.
At the Main Menu, tap History. By default the Tool History
screen is displayed.
Tool History
Vehicle History
Tool History
Use Tool History to view test total history as well as
in vehicle and out of vehicle test totals. Individual
test results are also displayed.
>
Tap
to view individual test details. Tap ∑ to view Total
By Test Decision, Total By Test Type, and Total By Date And
Location. Tap Done to return to the Tool History screen.
Totals By Test Decision
The totals are displayed by possible results for all battery
chemistries and potential test results.
Good Battery
Good Recharge
Aborted
Totals By Test Type
Displays test totals by test type.
RP129 Test
Multi-Battery Test
Cable Drop
Totals By Date And Location
Displays test totals by time interval. Also displays the number
of tests performed in and out of vehicle.
Chapter 9: History
User History
∑
Totals
Charge & Retest
Replace Battery
24 Volt Test
Out of Vehicle Test
Last 7 Days
Last 30 Days
Last 90 Days
Vehicle History
Vehicle History displays test totals conducted
on specific vehicles based on Vehicle ID. It is
also possible to enter a Vehicle ID to search for
test records for a specific vehicle by tapping the
displayed buttons.
Tap on the records displayed on the right side of the screen to
view the individual test results.
Vehicle Select Option
Tap
to select vehicle search option.
Manual Vehicle ID Lookup: Use the on-screen keypad to
manually type the Vehicle ID and tap Next.
Search: Search records by Vehicle Year, Make, and Model.
User History
User History displays test totals for the user that is
currently logged in to the analyzer.
>
Tap
to view individual test details.
Tap ∑ to view Total By Test Decision, Total By Test Type, and
Total By Date And Location.
Totals By Test Decision
The totals are displayed by possible results for all battery
chemistries and potential test results.
Good Battery
Good Recharge
Aborted
Totals By Test Type
Displays test totals by test type.
Cable Drop
RP129 Test
Totals By Date And Location
Displays test totals by time interval. Also displays the number
of tests performed in and out of vehicle.
Last 7 Days
Last 30 Days
Last 90 Days
Chapter 9: History
In Vehicle
Out Vehicle
Charge & Retest
Replace Battery
Multi-Battery Test
In Vehicle
Out Vehicle
