DSS-5000 HD
VIN A unique code, including a serial number, used to identify individual motor vehicles, motorcycles,
scooters and mopeds, as defined in ISO 3833.
Vehicle Year Model year that a vehicle was manufactured.
Vehicle Make Vehicle manufacturer
Vehicle Model Vehicle name or number
Hybrid, Gasoline, Electric, Start-Stop, Hybrid Start-Stop, Diesel
Vehicle Technology
Mileage Mileage of vehicle being tested
Pack Single or dual battery pack
Alt Remote Sense Vehicle remote option to detect voltage at the alternator rather than the battery pack
Battery Application Automotive, Marine, Powersports, Group 31, Commercial 4D/8D, Lawn and Garden
Battery Type Flooded, AGM (Absorbed Glass Mat), AGM Spiral, Gel, Enhanced Flooded, NorthStar Odyssey Pure Lead
Battery Units
CCA
CA
JIS
DIN(A)
SAE(A)
IEC(A)
EN(A)
EN2(A)
Battery Rating Enter the Battery Rating Units value.
RC/Ah Test Reserve Capacity or Amp Hours
Reserve Capacity/ Enter numeric value for Reserve Capacity or Amp Hour value
Amp Hours
Notes Enter specific job notes or RO number
Num of Batteries Enter a numeric value for the number of batteries in the pack being tested.
NOTE: If no Reserve Capacity/Amp Hours value is entered, the analyzer will use the average RC rating for a flooded
Group 31 battery (180 minutes).
Appendix B: Test Parameters
Cold Cranking Amps: Battery current at 0 ºF (–17.8 ºC).
Cranking Amps: Battery current at 32°F (0 ºC).
Japanese Industrial Standard: Usually printed on battery label.
Deutsches Institut für Normung
European labeling of CCA
International Electrotechnical Commission
Europa-Norm
Europa-Norm
Appendix B: Test Parameters
100 to 3000
100 to 3000
26A17 to 245H52
100 to 1000
100 to 3000
100 to 1000
100 to 1700
100 to 1700
