Midtronics DSS5000PHDKT User Manual page 34

DSS-5000 HD
Battery Test Results
Reserve Conductance
Capacity Result
Good Good
Good-
Good
Recharge
Charge &
Good
Retest
Replace
Good
Battery
Bad Cell-Short
Good
Replace
Warning Good
Good-
Warning
Recharge
Charge &
Warning
Retest
Replace
Warning
Battery
Bad Cell-Short
Warning
Replace
No Test Good
Good-
No Test
Recharge
Charge &
No Test
Retest
Replace
No Test
Battery
Bad Cell-Short
No Test
Replace
Appendix A: Test Result Descriptions
Overall
State Of Health Message
Result
Battery meets or exceeds required
Good
standards. Test again in 90 days or at next
Battery
service opportunity.
Battery is good, but low on charge. Fully
Good-
charge the battery for optimal performance
Recharge
and life. Check for causes of low charge.
Charge & Battery requires charge to determine
Retest condition.
Replace Battery fails to meet industry accepted
Battery standards.
Bad
Battery fails to meet industry accepted
Cell-Short
standards.
Replace
Battery is good for cranking purpose but
Replace shows low reserve capacity. Low reserve
Battery capacity will comprise the battery's ability to
provide system current and hold a charge.
Battery is good for cranking purpose but
Replace shows low reserve capacity. Low reserve
Battery capacity will comprise the battery's ability to
provide system current and hold a charge.
Battery is low in charge and shows low
Replace reserve capacity. Low reserve capacity
Battery will comprise the battery's ability to provide
system current and hold a charge.
Replace Battery fails to meet industry accepted
Battery standards.
Replace Battery fails to meet industry accepted
Battery standards.
Battery meets or exceeds required
Good
standards. Test again in 90 days or at next
Battery
service opportunity.
Battery is good, but low on charge. Fully
Good-
charge the battery for optimal performance
Recharge
and life. Check for causes of low charge.
Charge & Battery requires charge to determine
Retest condition.
Replace Battery fails to meet industry accepted
Battery standards.
Bad
Battery fails to meet industry accepted
Cell-Short
standards.
Replace
Appendix A: Test Result Descriptions
Reserve Capacity Message
The battery has sufficient reserve capacity
to provide power for the electronics
systems in the vehicle.
The reserve capacity of the battery is
low. Low reserve capacity of the battery
could impact the ability of the battery to
provide power for the electronics systems
in the vehicle, such as console screen,
entertainment systems, power seats, etc.
Recommend replacing the battery.
System conditions have prevented a test of
the battery reserve capacity in this vehicle.
Before attempting any retest, ensure that
all vehicle accessory loads are off, the key
is not in the ignition, and the doors are
closed.
