Chapter 8: Digital Multimeter

Meter Specifications

Meter Range Resolution
Vdc 0 V–30 V
Vac 0 V–20 Vac
Adc Low 0 mA–70 A
Adc High 0 A–700 A
Aac Low 0 A–20 A
Aac High 0 A–200 A
Accuracies are specified from 2% to 100% of range.
Meter Range
Ohm 0Ω–1MΩ
Temperature -30˚C to 70˚C
Accuracy specification defined as
± (n% reading + [count * resolution]) at 77 °F.
Accuracy
0.01 V ± 1% of reading + 0.05V
0.01 V ± 1% of reading + 0.05V
0.01 A ± 2% of reading ± 0.1A
0.1 A ± 2% of reading ± 0.1A
0.01 A ± 2.5% of reading ± 0.1A
0.1A ± 2.5% of reading ± 0.1A
Resolution Accuracy
1Ω ± 3.5% of reading
± 1Ω
1˚C ± 1˚C
