DSS-5000 HD
Display
Adjust the Controller display including the Brightness,
Sleep Time, and Dim Time. Auto Brightness can also
be turned on and off.
Brightness
Adjust the display Brightness by tapping and holding the
slider, then moving it right or left to make the screen brighter
or darker.
Auto Brightness
Enable and disable Auto Brightness by taping on the check box.
Sleep Time
Adjust the amount of elapsed time before the Controller goes
into a power saving (Sleep) mode. Default = 2 minutes.
Dim Time
Adjust the amount of elapsed time before the Controller goes
into a power saving (Dim) mode. Default = 1 minute.
BMIS Login (Admin Only)
Enter and edit BMIS Login and Password information.
Log into a BMIS account.
Login
Password
Shop Information (Admin Only)
Access default Shop Information including Store
Name, address, and phone number. Also access
battery test defaults including rating, temperature
units, and decimal separator. Use also to adjust the
tester date and time settings.
Settings Home
Test Settings
Zone3@yourshop.com
• • • • • •
Date/Time Settings
Create MDCA Log File
∑
Shop Information
Use the on screen keypad to enter the store name, address,
and phone number.
Store Name
Street Address
Street Address 2
City
State
Zipcode
Phone #
Test Settings
1. Tap to access the test setting defaults. Tap the boxes or
icons to change the values.
Battery Rating
Temperature Units
Decimal Separator
Create MDCA Log File
Battery Rating
Default battery rating units used when testing batteries.
Temperature Units
Default temperature units used when measuring battery
temperature.
Decimal Separator
Default number display using commas or periods separators.
Create MDCA Log File
The MDCA function is used by Midtronics technical support.
2. Tap to return to the Shop Information screen.
Date/Time Settings
1. Tap to access the Date/Time setting defaults.
Select Time Format
Select Date Format
Select Time Zone
Set Date
Set Time
Select Time Format
12 or 24 Hour Format
Select Date Format
Month/Day/Year, Day/Month/Year, or Year/Day/Month
Select Time Zone
Time zone in which the analyzer will be operated.
Chapter 11: Settings
Midtronics
7000 Monroe
Willowbrook
IL
60527
1-630-323-2800
CCA
0 F
00.00
12 Hour
10/18/2016
EST
