7.3.2 Equipotential bonding and earth rail
Rev. 08.08.23
Optional for wind deflectors at the rear in the last row
and/or for ballast containers.
MANUAL FOR FLATFIX FUSION MOUNTING SYSTEM FOR FLAT ROOFS
Earth rail
Multi-core cable (6mm
)
2
End clamp + grounding clamp
Module clamp + equipotential
Grounding bracket (optional)
27
