Mechanical Installation
4
Screw in
but not tighten
Mark
14
5
M5
8.8 lbf.in /
1.0 N·m
Cross screwdriver
Marker
Spirit level
CAUTION!
Please re-mount the dust cover to the battery module before drilling
holes to avoid dust falling into the interface and do remember to
remove the dust cover again after the installation wall bracket
completed.
6
7
Mechanical Installation
φ 10drill
Depth:
3.54 in / 90 mm
15
