SolaX Power QUICK INSTALLATION GUIDE Quick Installation Manual page 7

Overview of Terminals
BI communication terminal (Purchased by customer)
No. Port Pin
Terminals
Pin 1: RESERVE
Pin 2: RESERVE
Pin 3: CAN_L
Pin 4: CAN_H
13 INV
Communicatio Pin 5: RS485_BI_A
n terminal
Pin 6: RS485_BI_B
Pin 7: +12 V
Pin 8: GND
Pin 1: DRY_GEN
Pin 2: GEND_GEN
Pin 3: RS485_RESERVE_A
AUX1
14 Pin 4: RS485_RESERVE_B
terminal
Pin 5: RESERVE
Pin 6: RESERVE
Pin 7: STOP_NO+
Pin 8: STOP_NO-
Pin 1: NO_1
Pin 2: COM_1
Pin 3: NC_1
Pin 4: NO_2
AUX2terminal
15
Pin 5: CON_2/3
Pin 6: NC_2
Pin 7: NO_3
Pin 8: NC_3
Pin 1: CT1+
CT1 terminal
16
Pin 2: CT1-
Pin 1: CT2+
CT2 terminal
17
Pin 2: CT2-
Pin 1: CT3+
CT3 terminal
18
Pin 2: CT3-
Pin 1: CT L1A+
CT L1A terminal
19
Pin 2: CT L1A-
10
Torque
Type Range Strip Length
(in-lbs)
CAT5 or
24-18 AWG
better
0.24 in / 6 mm 1.8
18-16 AWG
24-16 AWG
CAT5 or
better
0.24 in / 6 mm 1.8
24-18 AWG
0.24 in / 6 mm 1.8
24-16 AWG
Shielded,
/ / /
twisted pair
Shielded,
/ / /
twisted pair
Shielded,
/ / /
twisted pair
Shielded,
/ / /
twisted pair
No. Port Pin
Terminals
Pin 1: CT L1B+
CT L1B terminal
20
Pin 2: CT L1B-
Pin 1: CT L2A+
CT L2A terminal
21
Pin 2: CT L2A-
Pin 1: CT L2B+
CT L2B terminal
22
Pin 2: CT L2B-
BI breaker and switch (Purchased by customer)
No. Component Description
Amps Part Number Description
100 CSR2100 Eaton # CSR2100: 100 A / 240 V, 25 kAIC, 2-Pole
125 CSR2125N Eaton # CSR2125N: 125 A / 240 V, 25 kAIC, 2-Pole
150 CSR2150N Eaton # CSR2150N: 150 A / 240 V, 25 kAIC, 2-Pole
175 CSR2175N Eaton # CSR2175N: 175 A / 240 V, 25 kAIC, 2-Pole
200 CSR2200N Eaton # CSR2200N: 200 A / 240 V, 25 kAIC, 2-Pole
100 BW2100 Eaton # BW2100: 100 A / 240 V, 10 kAIC, 2-Pole
125 BW2125 Eaton # BW2125: 125 A / 240 V, 10 kAIC, 2-Pole
150 BW2150 Eaton # BW2150: 150 A / 240 V, 10 kAIC, 2-Pole
175 BW2175 Eaton # BW2175: 175 A / 240 V, 10 kAIC, 2-Pole
1
Grid breaker
200 BW2200 Eaton # BW2200: 200 A / 240 V, 10 kAIC, 2-Pole
100 BWH2100 Eaton # BWH2100: 100 A / 240 V, 25 kAIC, 2-Pole
125 BWH2125 Eaton # BWH2125: 125 A / 240 V, 25 kAIC, 2-Pole
150 BWH2150 Eaton # BWH2150: 150 A / 240 V, 25 kAIC, 2-Pole
175 BWH2175 Eaton # BWH2175: 175 A / 240 V, 25 kAIC, 2-Pole
200 BWH2200 Eaton # BWH2200: 200 A / 240 V, 25 kAIC, 2-Pole
Normally closed (NC) contact
Emergency
2
The UL certification is required for the emergency stop switch.
stop switch
Overview of Terminals
Torque
Type Range Strip Length
(in-lbs)
Shielded,
/ / /
twisted pair
Shielded,
/ / /
twisted pair
Shielded,
/ / /
twisted pair
11
