SolaX Power QUICK INSTALLATION GUIDE Quick Installation Manual page 16

Mechanical Installation
Cylindrical plastic
bubble spirit level
3
The steps of mounting battery modules, BMS and inverter are same as the floor-
mounting's. Please refer to Chapter 3.
28
4
26.5 lbf.in / 3.0 N·m
x 4
x 4
For solid wood wall
For concrete wall
M5
8.8 lbf.in /
1.0 N·m
5. Wiring Connection on the Inverter
• AC cable
A: L1 terminal B: L2 terminal
• PV cable
A, C and E: PV+ terminal
B, D and F: PV- terminal
Wiring Connection on the Inverter
ABC
12–8 AWG(for A1-HYB-G2
3.8 KW)
10–8 AWG(for A1-HYB-G2
5.0 KW / 6.0 KW / 7.6 KW)
0.47 in / 12 mm
Wirings
C: N terminal
A
B
C
D
E
F
2 MPPTs(for A1-HYB-G2 3.8
KW / 5.0 KW / 6.0 KW)
3 MPPTs (for A1-HYB-G2 7.6
KW)
10-8 AWG 0.47 in / 12 mm
29
Wirings
