1. Packing List
• Packing list of inverter
A
D
B
E
C
L
M
Item
Name
Description
A
Inverter X1
Product
B
Mental cover X1
Protect the inverter
C
Bracket X1
Support the inverter
Self-tapping screwX12
Fix the bracket
D
E
Expansion boltX12
Fix the bracket
WasherX12
Fix the bracket
F
M5X10 screwX10
Fix the cover, cable protective guard and cover fixing plate
G
Grounding terminalX5
For grounding
H
I
PE cableX1
Grounding cable between inverter and BMS
8 AWG ferrules X3
For AC cable
J
K
10 AWG ferrules X6
For PV cable
DocumentsX3
User manual, installation guide and quick installation guide
L
M
Circuit breakerX1
Mount it on the BI
N
Communication dongleX1
For communication
(Optional)
O
Cable protective guardX1
Protect the cable between inverter and BMS
P
Fixing plate of coverX2
Connect the cover and the bracket
8-pin female terminal block
Additional 8-pin female terminal block
Q
with terminating resistorX1
with terminating resistor
R
M4X10 screwX2
Fix the fixing plate between inverter bracket and BMS
