Mechanical Installation
Step 3 Mount the BMS
1
M5
8.8 lbf.in /
1.0 N·m
18
2
• Mount the inverter
Screw in the two M4 screws, adjust the bracket to be firmly attached on the wall
surface and tignen M4 screws
Hand remove
1
2
Mechanical Installation
M4
4.4 lbf.in /
0.5 N·m
Round holes
19
