Mechanical Installation
CAUTION!
Remove the screws on the bracket and disassemble the bracket
before drill holes.
3
20
4
Φ4 drill for wooden wall
Φ10 drill for concrete wall
Depth:
2.16 in / 55 mm
This step is not required in
case of wooden wall.
5
Back view
6
Mechanical Installation
10
mm
26.5 lbf.in /
3.0 N·m
Front view
21
