SolaX Power QUICK INSTALLATION GUIDE Quick Installation Manual page 3

Packing List
• Packing list of battery
BMS
( TBMS-MCS60060
)
A
Item
Name and Quantity
A BMS
B
User ManualX1
C
Safety instructionsX1
OneBattery Module (TP-HS50×1):
B
A G
Item Name and Quantity Description
A Product
Battery moduleX1
B
BracketX2 Support battery module to be mounted on the wall
C Expansion boltX4 Fix the bracket
Fix the bracket
D Expansion boltX2
E WasherX2 Fix the bracket
Fixing plate (3 holes)X2 Connect two battery modules with bracket
F
G Fixing plate (2 holes)X2 Connect two battery modules
M5*10 cross screwX10 Fix the fixing plate
H
I Quick Installation GuideX1
Guide the installation
NOTE!
The above-mentioned accessories are only for one battery module.
2
B C
Description
Product
Guide the installation and maintenance
Safety information for the battery system
C D E F
H I
Accessories for Both Floor and Wall Mounting (Separate Accessory Box)
A B
D F
Item Name and Quantity Description
A Support the base
Base supportX2
B
Transverse plateX1 Support the base
Expansion screwX6 Fix the base support in case of concrete wall
C
D M5*8 countersunk screwX4 Fix the transverse plate with base support
E M5*20 countersunk screwX6 Fix the two sides of base
Adjustment screwX2 Adjust the base to be leveled
F
G Fix the base support in case of wooden wall
Tapping screwX6
Packing List
C
G H
3
