- Page 1 Triple Power ---High Voltage Storage System www.solaxpower.com...
-
Page 2: Table Of Contents
CONTENTS OVERVIEW INTRODUCTION CERTIFICATION INSTALLATION STATUS INDICATOR TROUBLESHOOTING... -
Page 3: Overview
OVERVIEW Battery System AC Breaker PV Array DC Distribution Box ---Surge Arrestor Photovoltaic system consist ---Fuse ---DC Breaker • Solar cell module; ---Surge Arrestor DC Breaker ---Fuse • DC distribution equipment; ---DC Breaker • AC distribution equipment; AC Distribution Box •... - Page 4 OVERVIEW Quality Assurance · Passed a series of certifications, eg: TUV (IEC 62619) Flexible Scheme · 8 type of system can be chose. Easy Installation · Simple wire connection and fast installation.
- Page 5 OVERVIEW Features of Product: · 100% DOD; · 99% Charge Efficiency; · 95% Charge Discharge Cycle Efficiency; · Charge Cycle Life>6000; · Hardware Secondary Protection; · Classified Protection: IP55; · Safety & Reliable; · Little Space Taking; · Two Installation Methods: Floor Mounting & Wall Mounting;...
- Page 6 Triple Power System = Master Control + Slave Control + Battery 1、Master Control (BMS)：MC0500 (Must be chose when making order) 2、Battery Module：HV10040 & HV10056 Battery 3、8 Type of System： Module Model Battery Module Energy(KWh) Voltage(V) T-BAT H4.0 MC0500x1 HV10040X1 85-118 T-BAT H8.0 MC0500x1 HV10040X2 170-236 T-BAT H12.0 MC0500x1 HV10040X3 255-354 T-BAT H16.0...
- Page 7 OVERVIEW Parameter Specification: MC0500 HV10040 HV10056 Nominal Voltage(Vdc): 100.8 100.8 Operating Voltage(Vdc): 70-500 85-118 85-118 Nominal Capacity(Ah): Max. charge/discharge Current(A) : Recommend Charge/Discharge Current (A): Standard Power(kW): Maximum Power(kW): Faradic Charge Efficiency(25℃/77℉): Battery Round trip Efficiency(C/3,25℃/77℉): Expected Lifetime(25℃/77℉): 5 years Cycle life(100% DOD,25℃/77℉): 6000 cycles Available Operating Temperature:...
-
Page 8: Introduction
INTRODUCTION Port Port Lable Description Breather Valve XPLUG Power Port（Connect with battery module） Size：461*189*105mm RS485 RS485 Communication Port Net Weight：5.7kg DIP Switch Rough Weight：7.5kg ON/OFF Air Switch POWER Power Switch CAN Communication Port BAT+/BAT- Positive & Negative charge lines... - Page 9 INTRODUCTION Port Battery Module Port Lable Description XPLUG Power Port（Connect with the next one battery module YPLUG port） Size：464*193*588mm RS485 I RS485 communication port 1（Connection with battery Weight：56.6kg(40Ah) module’s communication port） 67.5kg(56Ah) Connect with ground RS485 II RS485 communication port 2（Connect with the next one...
-
Page 10: Certification
CERTIFICATION Certifications Battery pack safety: CE, FCC, RCM, TUV (IEC 62619), UL 1973 Battery cell safety: UL 1642 UN number: UN 3480 Hazardous materials classification: Class 9 UN transportation testing requirements: UN 38.3 International protection marking: IP 55... -
Page 11: Installation
INSTALLATION Design Sketch... - Page 12 INSTALLATION Complete Installation Drawing...
- Page 13 INSTALLATION 1. Floor/Wall Mounting Note • Customers are supposed to estimate the GND wire first according to their actual installation site; • Then connect GND wire with battery module; • Then start installing: floor mounting or Wall mounting; • Lastly, connect power line & Communication line between BMS and battery module;...
- Page 14 INSTALLATION 2. Power Line Connection a. Connect Power Line ( Length: 120mm) between BMS and Battery Module：BMS (XPLUG) with Slave Controller (XPLUG) BMS(Master Controller) Slave Controller Battery Module = Slave Controller + Battery...
- Page 15 INSTALLATION 2. Power Line Connection b. Using Short-circuit line to make a loop: if only one battery module, plug Short-circuit Line into this battery module’s YPLUG port when finishing the Power line & Communication line connection, so that can make a complete electric loop. Note If using 2-4 battery modules, you should use power line (Length: 400mm) to complete the connection between battery modules, and lastly, using Short-circuit line to make a complete electric...
- Page 16 INSTALLATION 2. Power Line Connection Actual Connection Diagram...
- Page 17 INSTALLATION 3. Communication Line Connection RS485 Connection: Connecting communication line (Length: 120mm) between BMS RS485 port and Battery Module’s RS485I port, then tighten the plastic nut. If more than one battery module (2-4 Battery Modules), after finishing the communication connection between BMS and First battery module, using Communication Line (Length: 400mm) to complete the communication connection between battery modules.
- Page 18 INSTALLATION 3. Communication Line Connection ：Connecting CAN Communication Line (Length: 2mm) between BMS CAN Port CAN Communication and Inverter CAN Port.
- Page 19 INSTALLATION 4. GND Connection (THIS IS MANDATORY REQUIREMENT) Using 10AWG GND line to connect GND Port between BMS and Battery Module, then, connect with inverter’s GND Port in the end.
- Page 20 INSTALLATION 5. Charge Line Connection Connect to Inverter : Using Power Line (Length: 2m) to complete connections between Inverter and BMS.
- Page 21 INSTALLATION 5. Communication Line Connection Connect to BMS: Using Power Line (Length: 2m) to complete connections between Inverter and BMS.
- Page 22 INSTALLATION 6. Commission a. Set the Air Switch to ON; b. Turn on the Power Switch(Note: Please make sure the interval time at least exceeding 10 seconds before next time to press button) ; c. Turn the Power Switch of the Inverter;...
-
Page 23: Status Indicator
STATUS INDICATOR BMS Status Indicator: Mode Status of BMS Active Green LED flashes once every 5s Protection Yellow LED flashes once every 5s Fault Red LED flashes once every 5s Configuring Green LED keeps on Upgrade for master module Green LED flashes quickly... - Page 24 STATUS INDICATOR BMS Status Indicator: 60% Power： Charge Discharge...
- Page 25 STATUS INDICATOR Battery Module Status Indicator: Note The Status Indicator of S1 and S2 is consistent. Mode Status of Battery Module Active Green LED flashes once every 5s Warning Yellow LED flashes once every 5s Protection Red LED flashes once every 5s Configuring Green LED keeps on Upgrade for master module...
-
Page 26: Troubleshooting
TROUBLESHOOTING Warning Message Description Troubleshooting BMS_External_Err The communication between BMS and Check if the communication cable between master module and Inverter is correctly and well connected. Inverter is interrupted BMS_Internal_Err DIP switch at the wrong position; Move the DIP switch to the correct position; The communication between slave Check if the communication cable between slave modules is correctly and well connected. - Page 27 Thank you!
