Wiring Connection on the Inverter
Diagram for communication connection steps between inverters
Step 1
8-pin
Step 3
Step 5
On the side of the first inverter
32
Step 2
Strip Length
0.24 in / 6 mm
24-18 AWG
Conduit
18-16 AWG
Step 4
Step 5
On the side of the second inverter
Diagram for communication connection steps between inverter and BI
Step 1
8-pin
Step 3
Step 5
On the side of inverter
Wiring Connection on the Inverter
Step 2
Strip Length
0.24in./6mm
24-18 AWG
Conduit
18-16 AWG
Step 4
Step 5
On the side of BI
33
