Mechanical Installation
3. Mechanical Installation (Floor-mounting)
• Mount the battery
Step 1 Mount the base
1
Bottom view
Top view
2
Mark
12
3
Hand remove
Spirit level
Torque wrench
Marker
Measuring tape
Step 2 Mount the battery module
1
2
3
Mechanical Installation
Hand remove
M5
8.8 lbf.in /
1.0 N·m
13
